To enable CrossFire Mode, you will need to:
•
Prepare one CrossFire
•
Make sure the graphics card driver supports the ATI CrossFire
latest driver from ATI website (http://www.ati.com).
•
Make sure your power supply unit is sufficient to provide the minimum power required.
1. Insert the CrossFire
card [Master Card] into the [PCIEXP1]
master slot on motherboard.
2. Insert the CrossFire
Express graphics card (Slave Card) into
the [PCIEXP2] slave slot.
3. There are 3 connectors on the
™
DMS-59 -to-interconnect cable:
Connector 1: [DMS-59
Connector 2: [DVI-I] Female connector
Connector 3: [DVI-I] Male connector
4. Connect the DMS-59
™
DMS-59 connector on Master Card.
5. Connect the DVI-I Male-end to the DVI-I
connector on Salve Card.
6. Connect the video output to your
monitor from the remaining DVI-I
Female-end.
※ The motherboard in this illustration is served for demonstration only, may not be
the same type or model as the one described in this user's manual.
2-16
™
Edition graphics card and one CrossFire
™
Edition graphics
™
compatible PCI
™
] Male connector
™
Male plug to the
™
Compatible graphics card.
™
technology. Download the
AW8D
