60 Hz

Model HP
MLZ015 2
MLZ019 2 ½
MLZ021 3
MLZ026 3 ½
MLZ030 4
MLZ038 5
MLZ042 5.5
MLZ045 6
MLZ048 7
MLZ058 7 ½
MLZ066 9
MLZ076 10
MLZ015 2
MLZ019 2 ½
MLZ021 3
MLZ026 3 ½
MLZ030 4
MLZ038 5
MLZ042 5.5
MLZ045 6
MLZ048 7
MLZ058 7 ½
MLZ066 9
MLZ076 10
MLZ/MLM015 2
MLZ/MLM019 2 ½
MLZ/MLM021 3
MLZ/MLM026 3 ½
MLZ/MLM030 4
MLZ/MLM038 5
MLZ/MLM042 5.5
MLZ/MLM045 6
MLZ/MLM048 7
MLZ/MLM058 7 ½
MLZ/MLM066 9
MLZ/MLM076 10
* at EN12900 conditions: To= -10°C, Tc= 45°C, RGT= 20°C, SC= 0K
** R507 performance data are nearly identical to R404A performance data
Motor voltage code 4: 400V/3~/50 Hz & 460V/3~/60 Hz
MLZ/MLM042: motor voltage code 1: 208-230V/1~/60 Hz
8
T

ECHNICAL SPECIFICATIONS

Nominal Power
cooling capacity * input *
W Btu/h kW
4100 13900 2.10
5500 18600 2.58
5800 19900 2.74
7200 24700 3.44
8500 29000 3.90
10200 34900 4.70
11100 37700 5.73
12400 42200 5.64
13500 46200 6.15
15700 53600 7.35
18400 62600 8.40
20900 71300 9.59
2500 8600 1.19
3200 11000 1.53
3400 11700 1.58
4200 14500 1.91
5100 17500 2.35
6000 20600 2.80
6500 22100 3.33
7300 25100 3.32
7800 26700 3.54
9400 32100 4.27
10800 36800 4.85
12100 41400 5.61
3900 13400 1.74
5200 17900 2.22
5600 19000 2.36
7000 23800 2.93
8200 27900 3.46
9600 32700 4.06
11000 37400 5.00
11700 39800 4.91
12900 43900 5.36
14900 50800 6.34
17000 58100 7.14
20100 68400 8.40
