Mlz/Mlm030-038-042-045-048 - Danfoss MLM Series Application Manuallines

A G
PPLICATION UIDELINES

MLZ/MLM030-038-042-045-048

D
IMENSIONS
239
190
134
121
1)
122
2)
34°
182.54 - 184.54
Discharge port
1/2" ODF
1)
3/4" ODF
2)
94
403
202
11
Terminal box
C
T₁
R
T₃
Ring connect screw terminals
C terminal box type
Refer to section "Ordering information and packaging" for overview of shipped mounting accessories
FRCC.PC.015.A4.02
4 x Ø 19
118
239
190
31°
45° 73°
Suction port 7/8" ODF
436
Oil sight glass
261
Schrader valve
and cap
85
56
19
Mounting grommet
S
29.5
T₂
Recommended torque for
mounting bolts: 11 Nm (±1 Nm)
MLZ/MLM 030-038-042-045
1)
MLZ/MLM 048
2)
All dimensions in mm
Ø11
Ø 41
13
