PRODUCT:
Designed Smart
Developed for high output!
• X*WAV™ Radiant Pass Through Conveyor Oven uses a series of
cutting edge controls and infrared heat systems that are focused at
your food, delivering an "extreme" level of heat energy for Broiling,
Toasting, Baking and Warming.
Heat Systems...the X*Treme Difference!
• The X*WAV™ ceramic heat system has over 31% more efficiency
in its InfraRed energy vs. Quartz based units.
• X*WAV™ heat system is a Concentrated, Pre-Focused source of
radiant energy that consistently sends InfraRed evenly toward the
conveyor belt...at both high and low temperature levels...InfraRed
efficiency is 96%!
X*Treme Control!
• X*WAV™ cooking control system utilizes a Solid State Digital Control
that is programmed to deliver a constant stream of energy to the
X*WAV™ elements.
Operations that are X*Tremely Easy & Efficient!
• Conveyor speed can be set between speeds that are slow
(12 minutes) to a maximum speed of 30 seconds.
• Conveyor direction can be reversed with switch on side of conveyor.
• Crumb trays are provided on either end of the toaster. 12" extended
conveyor shelves are supplied for both "entrance or exit" areas...
allowing easy loading and off-loading of products.
• Fully insulated top and sides provide "Cool to the Touch" exteriors...
keeping employees safe from burns. Thermostatically controlled fan
keeps exterior surface cool even when unit is turned off.
• X*WAV™ control panel is recessed vs. the "exposed" control panel on
the competition...reducing inadvertent bumps on control knobs that
change the performance speed or temperature.
Built Solid
Built to Last
• X*WAV™ Ceramic heaters are made of a stronger material that
maintains a moderate material temperature. They last significantly
longer than Quartz elements and do not have the issue of shattered
glass in your operation.
• Bottom heat is provided by a specially designed element that can
easily handle drippings and grease. Competitive units use quartz
elements that can shatter with grease drippings.
Reliability backed by APW Wyott's Warranty
• Certified by the following agencies:
APW Wyott Foodservice Equipment Company · 729 Third Ave., Dallas, TX 75226
(800) 527-2100 · (214) 421-7366 · Fax (214) 565-0976 · www.apwwyott.com · info@apwwyott.com
QUANTITY:
1
X*WAV™ 1422
Pass-Through Conveyor Oven
ITEM #:
X*WAV™ 1422 PASS THROUGH CONVEYOR OVEN
APW Wyott Design Features
• X*WAV™ ovens are designed to Toast, Broil, Bake and Warm a
variety of menu items while minimizing countertop space.
• Ceramic InfraRed heaters located on the top provide the most
efficient and effective radiant energy to the cooking area.
X*WAV™ bottom heat is provided by a specially designed
metal sheathed element that directs a concentrated level of
energy to the food.
• X*WAV™ solid state digital controls provide the maximum
amount of control to top and bottom heat.
• Conveyor belt direction switch to reverse flow of food.
• Thermostatically controlled fan cooling system keeps the
conveyor oven "Cool to the Touch" and extends the life of
critical components.
• Conveyor belt speed control and top & bottom heat control
enables different menu items to be cooked in the same oven...
provides superior flexibility.
• Product entry and exit openings are adjustable to 3 7/8" high.
• Removable extended load/unload shelf area for ease of
product removal.
• Removable crumb tray for fast and easy clean-up.
Options
• Stacking Kit (94000189)
• 3 Phase
See reverse side for product specifications.
Model:
X*WAV 1422
• End stop (94000151)
Rev. 2/1/2006
