APW Wyott X*WAV 1417 Specifications

Pass-through conveyor oven

Advertisement

Quick Links

PRODUCT:
Designed Smart
Developed for high output!
• X*WAV™ Radiant Pass Through Conveyor Oven usesa series of
cutting edge controls and infrared heat systems that are focused at
your food, delivering an "extreme" level of heat energy for Broiling,
Toasting, Baking and Warming.
Heat Systems...the X*Treme Difference!
• The X*WAV™ ceramic heat system has over 31% more efficiency in
its InfraRed energy vs. Quartz based units.
• X*WAV™ heat system is a concentrated, pre-focused source of
radiant energy that consistently sends InfraRed evenly toward the
conveyor belt...at both high and low temperature levels...InfraRed
efficiency is 96%!
X*Treme Control!
• X*WAV™ cooking control system utilizes a Solid State Digital Control
that is programmed to deliver a constant stream of energy to the
X*WAV™ elements.
Operations that are X*Tremely Easy & Efficient!
• Conveyor speed can be set between speeds that are slow (12
minutes) to a maximum speed of 25 seconds.
• Crumb trays are provided on either end of the toaster. An extended
conveyor shelf is supplied for "exit" area....allowing easy off-loading of
products.
• Fully insulated top and sides provide "Cool to the Touch" exteriors...
keeping employees safe from burns. Thermostatically controlled fan
keeps exterior surface cool, even when unit is turned off.
• X*WAV™ control panel is recessed vs. the "exposed" control panel
on the competition...reducing inadvertent bumps on control knobs that
change the performance speed or temperature.
Built Solid
Built to Last
• X*WAV™ Ceramic heaters are made of a stronger material that
maintains a moderate material temperature. They last significantly
longer than Quartz elements and do not have the issue of shattered
glass in your operation.
• Bottom heat is provided by a specially designed element that can
easily handle drippings and grease...competitive units use quartz
elements that can shatter with grease drippings.
Reliability backed by APW Wyott's Warranty
• Certified by the following agencies:
APW Wyott Foodservice Equipment Company · 729 Third Ave., Dallas, TX 75226
(800) 527-2100 · (214) 421-7366 · Fax (214) 565-0976 · www.apwwyott.com· info@apwwyott.com
QUANTITY:
X*WAV™ 1417
Pass-Through Conveyor Oven
ITEM #:
X*WAV™ 1417 PASS THROUGH CONVEYOR OVEN
APW Wyott Design Features
• X*WAV™ ovens are designed to Toast, Broil, Bake and Warm
a variety of menu items while minimizing countertop space.
• Ceramic InfraRed heaters located on the top provide the most
efficient and effective radiant energy to the cooking area.
X*WAV™ bottom heat is provided by a specially designed
metal sheathed element that directs a concentrated level of
energy to the food.
• X*WAV™ solid state digital controls provide the maximum
amount of control to top and bottom heat.
• Thermostatically fan cooling system keeps the conveyor oven
"Cool to the Touch" and extends the life of critical components.
Thermostatically controlled fan keeps exterior surface cool
even when unit turns off.
• Conveyor belt speed control and top and bottom heat control
enables different menu items to be cooked in the same oven...
provides superior flexibility.
• Product entry and exit openings are adjustable to 3 7/8".
• Removable extended unload shelf area for ease of product
removal.
• Removable crumb tray for fast and easy clean-up.
Options
• Stacking Kit (94000189)
• Right to Left Conveyor versions
• 208V (94101000)
• 240V (94401000)
See reverse side for product specifications.
Model:
X*WAV 1417
• End Stop (941000141)
• 3 phase
Rev. 5/22/2005
