INSTALLATION AND OPERATING INSTRUCTIONS
COUNTER DECK OVEN
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause
!
property damage, injury or death. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
Model Number
+1 (307) 634-5801 Phone
+1 (307) 637-8071 Fax
All manuals and user guides at all-guides.com
MODEL:
24 Hour Toll Free
Service Hot Line:
IMPORTANT FOR FUTURE REFERENCE
Serial Number
APW WYOTT Foodservice Equipment Company
P.O. Box 1829
Cheyenne, WY 82003
CDO-17
1-800-733-2203
1
R
Date Purchased
P/N 88379-44 9-05
+1 (800) 752-0863 Toll Free
www.apwwyott.com
!

Advertisement

Table of Contents
loading

Related Manuals for APW Wyott CDO-17

Summary of Contents for APW Wyott CDO-17

  • Page 1 Warranty Service and/or Parts, this information is required. Model Number Serial Number Date Purchased P/N 88379-44 9-05 APW WYOTT Foodservice Equipment Company P.O. Box 1829 Cheyenne, WY 82003 +1 (307) 634-5801 Phone +1 (800) 752-0863 Toll Free +1 (307) 637-8071 Fax...

  • Page 2: Maintenance

    Maintenance & repair should be handled by a factory authorized agent. Before doing any maintenance or repair, contact APW Wyott Technical Service Department at (800) 752-0863 or (307) 634-5801. MAINTENANCE WARNING: Never clean any electrical unit by immersing it in water. Turn off before cleaning surface.

  • Page 3: Table Of Contents

    Check if the power switch is on and the indicator light is glowing. Check the data plate and make sure the unit is operating on the proper voltage. If the above checks out and you still have problems, call an APW Wyott Foodservice authorized service agency.

  • Page 4: Safety Precautions

    NOTICE: THESE PROCEDURES MUST BE PERFORMED BY QUALIFIED PERSONNEL OR WARRANTY WILL BE VOIDED.. SPECIFICATIONS Electrical: CDO-17 120 Volts, 50/60 Hz, 13 amps, 1 Phase, 1.5 KW 208/240 Volts, 50/60 Hz, 7.7/9.0 amps, 1 Phase, 1.6 KW/21.4 KW Dimensions Unit: 21-3/4"...

  • Page 5: Replacement Parts

    All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST Item Part Number Description Quantity 825178-10 Frame Assembly 825755-01 Shelf/Heater Support Assembly 31007-45 Shelf 14044-15 Heater 81 058-00 Support Assembly Mounting Screw Supplied w/Heater Mica Washer Supplied w/Heater Flat Washer 841 04-00 Nuts 300501-10...

  • Page 6: Installation

    All manuals and user guides at all-guides.com INSTALLATION The CDO-17 Bake Oven has been inspected and tested at the factory prior to shipment. The CDO-17 is designed for counter top operation. Equipment Preparation Unpack the CDO-17 and remove all packing materials (make sure no parts are discarded with crating material).

  • Page 7: Wiring Diagram

    All manuals and user guides at all-guides.com Unscrew case mounting screws (Item 38) and lift off case (Item 37). Unscrew the nuts (Item 8) from the rear of the heater to be replaced and disconnect the wiring. If top heater is being replaced, pry down the support tabs just far enough to slip the heater out. Remove the old heater;...

  • Page 8: Warranty

    APW Wyott's option or its Authorized Service Agency, it will be serviced on site or replaced. From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott Authorized Service Agency for in-warranty repairs.
