ASSEMBLY INSTRUCTIONS
DENVER 4'6 BED PINE
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING
YOUR DENVER 4'6 BED FRAME
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
HEALTH & SAFETY:
DO NOT jump on this bed frame
DO NOT use this bed frame if any parts are missing, damaged or worn
DO NOT use this bed frame unless all xings are secured
Always use on a level, even surface
WARNING: If this bed is placed on a laminated oor you must place some protection under all legs
to stop the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame
collapses
CARE & MAINTENANCE:
Periodically check all screws & xings to ensure they are secure
DO NOT push the bed frame as this will damage the legs
Always lift the bed with two people to reposition
Keep any sharp objects away from the frame
3 m
www.birlea.com
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DENVER 4’6 BED PINE and is the answer not in the manual?

Questions and answers

Summary of Contents for Birlea DENVER 4’6 BED PINE

  • Page 1 Periodically check all screws & xings to ensure they are secure DO NOT push the bed frame as this will damage the legs Always lift the bed with two people to reposition Keep any sharp objects away from the frame www.birlea.com Page 1 of 4...
  • Page 2 Vendor: S000107 HARDWARE LIST ( FOUND IN BOX 02) Item Item ¼* 90 mm Bolt Post Headend Post Footend 4*35 mm Screw 10 x 40 mm Wooden Dowel Post Footend Post Headend Grids Allen Key 4*16 mm Screw Footend Rail Headend Rail 7 x 90 mm Bolt...
  • Page 3 Vendor: S000107 Step 2: Attach a plinth (10) to the headend (5) using hardware part H. DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 3: Fix hardware part L to the headend (7) using hardware part F, then attach the side rails (8) using hardware parts A, C and E DO NOT use any power tools as this may damage the frame and will invalidate any claim Page 3 of 4...
  • Page 4 Vendor: S000107 Step 4: Secure the centre rail (9) using hardware part F DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 5: Fix the slats (11) into position whilst applying pressure to both side rails (8) using hardware parts B and J and a screwdriver (not provided) DO NOT use any power tools as this may damage the frame and will invalidate any claim B 00567...
