4. Using the program tools

Left view
Right view
Real-time image
view
Freeze-screen
Negative view
Capture
Series-Capture
Rotation
Open folder
To show the left side of a book
To show the right side of a book
To show images of the book on the screen in real time. A click on the
button displays Freeze-screen.
To freeze a captured image on the screen.
A click on the button displays Real-time image view.
Click on either R or L
To show the color of an image in reverse form
<Original image>
To scan the current page and save it in a file. The destination can be
set in "Path for Captured" of III. 3. 2) Program setting. The basic
folder name is "Capture Image"/ "YYYY-MM-DD"(Year-Month-Date)
and basic file name is "HH_MM_SS"(Hour_Minute_Second). In
writing mode, the objects that are drawn or written on the image are
saved together.
To save left and right sides in image file format. The currently
viewing page is saved first and then the opposing side follows. The
path is assigned to Captured Image Save folder.
To display an image turning at 90 degrees clockwise. The rotation
value is saved and later applied in the same form when uploading the
image.
To open Captured Image Save folder to verify the image saved in the
scan mode.
- 21 -
III_Operating VisualTable
to bring up a new page.
<Negative image>
