Sharpness: to adjust the clarity of an image. The farther it goes to right, the sharper it becomes
rougher.
Gamma: to adjust the gamma value in order to control the degree of the boundary of an image.
The farther it goes to right, the higher contrast range it has.
White balance: to adjust the value for grayness. You are advised to set it to Auto.
Backlight compensation: to compensate for backlight. (To the right for Application))
Normal rotation: to rotate an image when running the program Set the rotation
to 90˚ for a book employing a normal horizontal writing method.
Default magnification: to set a magnification shown at default when running the program.
Assuming a book of normal size showing on a 1280 X 1024 screen, you are advised to select an
80% magnification.
Image compensation: to enable or disable the function by marking a V in the box.
Check the V allows you to view images of a better resolution: however, you have to bear a slower
display of images
Enabling image compensation: to check the box
Disabling image compensation: to leave the box unchecked.
Background color: to select a background color that is shown other than where images are
displayed
Scan delay time: to determine time for a page to properly settle itself after the screen changes
from left to right or vice versa. The image does not appear properly when the computer
produces it at a slow speed or the scan time is too short to substantiate a clear image. Normally,
it takes a personal computer about 3~5 seconds, or more than 9 seconds for a computer with
low specifications. (Initial basic setting: 5 seconds)
Help: see the User Guide or click "http://blog.naver.com/smartbookscanner"
10
- 18 -
III_Operating VisualTable
