Droplet SP2 Manual

Beam-scan camera and software
Hide thumbs Also See for SP2:
Table of Contents

Advertisement

Quick Links

Download this manual
Manual for SP2
Beam-Scan Camera
and Software
2400 Trade Centre Avenue
Longmont, CO 80503 USA
DOC-0175 Revision D
A L L R I G H T S R E S E R V E D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP2 and is the answer not in the manual?

Questions and answers

Related Manuals for Droplet SP2

Summary of Contents for Droplet SP2

  • Page 1 Manual for SP2 Beam-Scan Camera and Software 2400 Trade Centre Avenue Longmont, CO 80503 USA DOC-0175 Revision D A L L R I G H T S R E S E R V E D...
  • Page 2 General Information In no event will Droplet Measurement Technologies, LLC (DMT) be liable for direct, indirect, special, incidental or consequential damages resulting from any defect or omissions in this manual. DMT reserves the right to make changes to this manual and the products it describes at any time, without notice or obligation.

  • Page 3: Table Of Contents

    Figure 3: SP2 Laser Beam in the TEM Mode, as viewed in the Graphical Plot ..... 8 Figure 4: The SP2 Laser Beam in a Higher-Order Mode, as viewed in the vBeam Control Window ......................9 Figure 5: The SP2 Laser Beam Plot in a Higher-Order Mode ........10 Figure 6: The SP2 Laser Beam Viewed Graphically in a Higher-Order Mode ....
  • Page 4 The SP2 beam scan camera and software is designed to facilitate observing and setting the mode of the YAG laser in the SP2. The system consists of a Mightex CCD camera which has been fitted with a high Optical Density (OD) filter. A mounting bracket allows the camera to be mounted in the position normally occupied by the YAG power monitor on the SP2.
  • Page 5 MAXIMUM of 70mW only under certain conditions, which are unspecified. Operation of the camera on the SP2 with any neutral density filter having an OD of less than 2 will void the warranty of the product. The Measured leakage should be between 80 –...
  • Page 6 These are initialized by clicking on the appropriate boxes in the View menu of the tool bar. Turn on the SP2 instrument, and if the Visulux software is being used on a separate computer, the standard SP2 startup and operation is recommended. If...

  • Page 7: Figure 1: Sp2 Laser Mode In The Tem Oo Mode, As Viewed In The Vbeam Control Panel

    (normal or even distribution) but the top of the view is flat in the plot or profile views, this is caused by measurement saturation. The exposure time should be reduced to change this. Figure 1: SP2 Laser Mode in the TEM Mode, as Viewed in the vBeam Control Panel DOC-0175 Rev D ©...

  • Page 8: Figure 2: The Sp2 Laser Beam In The Tem Oo Mode, As Viewed In The Surface Plot

    Figure 2: The SP2 Laser Beam in the TEM Mode, as Viewed in the Surface Plot Figure 3: SP2 Laser Beam in the TEM Mode, as viewed in the Graphical Plot. The upper plot shows the beam slightly out of adjustment and not following the Gaussian curve.

  • Page 9: Figure 4: The Sp2 Laser Beam In A Higher-Order Mode, As Viewed In The Vbeam

    If the above tests show that the SP2 YAG laser beam is in a satisfactory mode, no further adjustments are needed. Upgrades to the Visulux software are planned in the future to allow for continuous logging of the data, and this may be useful while collecting data with the SP2.

  • Page 10: Figure 5: The Sp2 Laser Beam Plot In A Higher-Order Mode

    Figure 5: The SP2 Laser Beam Plot in a Higher-Order Mode Figure 6: The SP2 Laser Beam Viewed Graphically in a Higher-Order Mode DOC-0175 Rev D © 2017 DROPLET MEASUREMENT TECHNOLOGIES...
  • Page 11 Start the YAG laser and observe the laser beam profile. For SP2 instruments SN 007 and above, insert a 5/64” ball driver into the access hole. SP2 instruments below this serial number require a 1/8” ball driver. It can be useful to use a flashlight to look into the access hole and locate the position of the adjustment screw.

  • Page 12: Troubleshooting

    If it is not, highlight this. Appendix A: Changes to Manual Revision Date Revision # Summary Section 4-8-10 Updated assembly drawing Appendix B 1/10/17 General updates All Sections DOC-0175 Rev D © 2017 DROPLET MEASUREMENT TECHNOLOGIES...
