Transmitter Operating Modes

4.1 Transmitter TEST and TRANSMIT Mode

When the power is on, the Transmitter defaults to the Test mode. In this mode
you can measure AC or DC voltage with the test leads. In this mode you can
also transmit a signal. Press the TEST/STOP button to allow the Transmitter
to send a signal. Press the TEST/STOP button again to switch the signal OFF.

4.2 Transmitter LEVEL Selection Mode

Press the LEVEL button to access the transmission strength selection mode,
the 'LEVEL' symbol text will flash. Use the up/down arrow buttons to select
the strength of the transmission signal (level: 1~3). Press the LEVEL button
again to return to the Test Mode. Select signal level '3' when using the ground
spike.

4.3 CODE Selection Mode

Codes can be used to differentiate two or more transmitters that are being
used to detect a break in a circuit.
Long press the CODE button to access the code selection mode, the 'CODE'
text symbol will flash. Use the up/down arrow buttons to select a code (F, E, H,
d, L, C, O, A). Press the CODE button again to return to the Test Mode.
