50
C
6: C
HAPTER
ONFIGURING
R
S
EDUNDANT
ERVER
7 Select the serial number of the peer device. In this case, the peer device is
the second Server Load Balancer.
8 Click Next. The Getting Started - IP Settings page appears.
If you change these settings, you may lose IP connectivity to the Web
interface upon completion of this wizard. If this occurs, you will need to
reconnect to the Server Load Balancer using the new IP address.
9 The IP Address, Subnet Mask and Default Router fields are completed.
These is the information you assigned to the Server Load Balancer during
the CLI setup.
10 Enter 10.20.30.56 in the Device B IP Address field.
This is the IP address assigned to the second Server Load Balancer.
11 Click Next. The Getting Started - Network Address Translation page
appears.
If you are using private IP subnets for your server or cache subnets and
want the servers or caches to be able to initiate connections to the
outside, check NAT Enabled for Server and Cache Subnets. If
NAT is enabled, packets initiated by the servers and the caches need to be
given an IP address on the primary IP subnet. This address is the alias
address.
12 Click Next. The Getting Started - Password page appears.
CAUTION: The Server Load Balancer does not provide a way to recover a
lost password. If you choose to assign a new password, it is suggested
you keep note of it in a safe place. If you forget your password, you will
be locked out of the unit. If you change the password during the CLI
Server Load Balancer setup, this is the password you should use, and not
the blank default login password. For Technical Support information, see
Appendix C.
13 Click Next. The Getting Started - Advanced page appears
14 Click Continue with Advanced Settings and click Next.
15 Select Active-Active and click Next. The Getting Started - Summary page
appears.
16 Click Finish. The parameters you have entered are ready to be applied.
You are now ready to configure the load balancing services. See Chapter
8 Configuring for Load Balancing.
L
B
OAD
ALANCING
