Harman JBL EON315 Technical Manual

Technical Manual
JBL EON315
SPECIFICATIONS
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• System Power Rating:
• Frequency Response:
• Frequency Range:
position)
• LF Power Amp:
• HF Power Amp:
• Input Gain:
• Input Inpedance:
• Boost EQ:
• Low Cut Filter:
• Maximum SPL:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Baffe/Grille Assembly:
• Low Frequency
Transducer:
• DC Resistance:
PACKAGE
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
280W continuous, 560W peak
50 Hz – 18 kHz (± 3 dB) (EQ in "Flat"
position)
38 Hz – 20 kHz (-10 dB) (EQ in "Flat"
220W continuous at driver impedance
60W continuous at driver impedance
Mic position: - Infinity to +40 dB
Line position:- Infinity to +4 dB (+20 dBu
Max signal input)
64 K ohms (balanced), 32 K (unbal
anced)
LF +3 dB Shelving Filter @ 150 Hz
HF +2.5 dB Shelving Filter @4 kHZ
Preset high pass @ 120 Hz
127 dB
1.8 kHz
441956-001
M115-2 380 mm (15 in)
1.4 ohm ±10%
Warranty 59660
Owners Manual
440940-001
(available from
web-site only)
Fillers, (2)
364823-001
Bag
322591-001
19" x16" x 42" LG
.003 THKLDPE CLR
Carton
364824-001
Cord, AC, Line
425-00000-00 120V
425-00000-01 230V
SYSTEM COMPONENTS:
(CONT'D)
• High Frequency
Transducer:
• DC Resistance:
• Input connector:
• Output Connector:
• XLR Pin Assignments:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Driver, High Freq
2414H-1
(363858-001X)
- +
BLU/BLK
0.205
BLU
0.250
SEE SCHEMATIC PAGE
2414H-1 25.4 mm (1 in) polymer
diaphragm, neodymium compression
driver
3.60 ohm ±0.2%
Balanced XLR / 1/4 inch TRS combo
jack
Balanced male XLR, +20 dBu (peak)
Pin 2 (+), Pin 3 (-), Pin 1 (GND)
200V Input, 20 Hz to 20 kHz
Sweep Duration: 5 seconds
Volume Control Full Clockwise
3.5V Input, 20 Hz to 2 kHz
.75V Input, 500 Hz to 1.5 kHz
685 x 438 x 366 mm D
(27 x 17.3 x 14.4 in D)
35 lb (15.9 kg.)
Driver, Low Freq
M115-2
(365153-001)
+
-
GRN/BLK
0.205
GRN
0.250
Amplifier Assembly
Wire Harness Assembly
365375-001
11-12
