Harman JBL WIND Owner's Manual

2 in 1 - on the road and on the go speaker
Hide thumbs Also See for JBL WIND:
Table of Contents

Advertisement

Quick Links

2 in 1 - On the road and on the go speaker
Owner´s manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JBL WIND and is the answer not in the manual?

Questions and answers

Related Manuals for Harman JBL WIND

Summary of Contents for Harman JBL WIND

  • Page 1 2 in 1 - On the road and on the go speaker Owner´s manual...

  • Page 2: Product Overview

    Product Overview Congratulations for purchase of WIND! To ensure a proper use of WIND please read this manual before you start to use. Also, please safely keep this manual for future reference and trouble shooting. Package Contents 1. 1x WIND BT Speaker main unit 2.

  • Page 3: Product Interface

     Carabiner and bicycle bar mounter with bracket are provided for two uses in carrying it over. Product Interface Handle for hanging a carabiner Play/pause (BT, aux and micro SD / TF), FM Scan and Mute (Radio) Volume + ( Long press ) - All functions Next (Short press) - BT, micro SD / TF and radio functions Volume –...

  • Page 4: Getting Started

    Click the "+" and "-" buttons to advance and return the radios respectively. When you turn on your JBL WIND for the first time, after playing the radio, press the "Play / Pause" button up to start scanning th FM radios of your region as soon as your radio is ready for use.
  • Page 5 Speaker Phone After paired your mobile phone to WIND with BT, the speaker phone function can be used.  Make call : Call will automatically transfer to the speakerphone. If not, tap play/pause button;  Answer call: Tap play/pause button to answer the incoming call; ...

  • Page 6: Technical Parameters

    Technical parameters Note: All specifications are subject to change without notice. Product name: Wind Power Supply: USB 5V, 1A Built-in Lithium Ion battery: 3.7V 800mAh Output power: 3W RMS BT Profile Supported: A2DP, AVRCP BT Version: 4.1 Working range: up to 10m Working atmosphere: 0°C 40°C / 20% 90% RH Memory card capacity: 32GB SPL Max: 80dB...

  • Page 7: Safety Instructions

     Check for other BT devices around the surroundings that may interfere with searching and turn devices off.  Power off and then power on the unit to restart the BT function of the unit or your BT device.  Unplug any cables plugged into the AUX IN, restart all devices and then attempt pairing again.
  • Page 8  Regardless of what reasons cause the unit damage, have the repair performed only by on authorized JBL dealer or service center;  If you want to do the cleaning, please turn off the unit and unplug the power cable from the outlet first; ...
  • Page 9 Warning: WIND is designed as multipurpose speaker which includes common and casual use on a bicycle as an entertaining device. We are not liable to risk in using WIND while you ride on a bicycle for speed racing, BMX performance, down hill riding, jumping and etc.
  • Page 10 © 2017 HARMAN International Industries, Incorporated. All rights reserved. Harman do Brasil Industria Eletrônica e Participações Ltda. is a trademark of Harman International Industries, registered in the United States and/or other countries. Features, specifications and appearance are subject to change without notice.
