- Page 1 VIEWEG Dosier- und Mischtechnik User Manual Diaphragm Valve DV-5625 Series V2018/08-01 © VIEWEG GmbH...
-
Page 3: Table Of Contents
Bedienungsanleitung Membranventil DV-5625-U / -SS Manual diaphragm valve DV-5625 Series VIEWEG Dear Customer Thank you for purchasing the diaphragm valve DV-5625. These operating instructions are intended for simple and safe operation of the valve. Please read these instructions carefully before putting the valve into operation and observe the given safety instructions. -
Page 4: Introduction
Bedienungsanleitung Membranventil DV-5625-U / -SS Manual diaphragm valve DV-5625 Series VIEWEG 1 Introduction The valve DV-5625 is a diaphragm valve designed for precise flow control of low to medium viscosity materials (under 10,000 cps). The valve is ideal for dispensing cy- anoacrylates, reagents, electrolytes, glues, solvents, paints, alcohol and other volatile substances. -
Page 5: Part Description
Bedienungsanleitung Membranventil DV-5625-U / -SS Manual diaphragm valve DV-5625 Series VIEWEG 3 Part description Driving Part Dispensing part 1 Flow rate adjust knob Diaphragm 2 Scale Material Input G 1/8“ 3 Air inlet (M5) Material output 4 Mounting hole (backside) -
Page 6: Operation Principles
Bedienungsanleitung Membranventil DV-5625-U / -SS Manual diaphragm valve DV-5625 Series VIEWEG 4 Operation Principles Dispensing OFF Dispensing ON Stroke short long py 2 copy 3 Quantity small large copy 1 copy 2 copy 1 copy 1 copy 2 copy 1... -
Page 7: Operating Procedure
Bedienungsanleitung Membranventil DV-5625-U / -SS Manual diaphragm valve DV-5625 Series VIEWEG 5 Operating Procedure compressed air supply dispensing valve material in controller cartridge control air dispensing dispensing material in material in material container Valve bottle material feed control air input... - Page 8 Bedienungsanleitung Membranventil DV-5625-U / -SS Manual diaphragm valve DV-5625 Series VIEWEG Note: Do not turn the fitting too deeply into the valve. 4. Place a suitable dispensing tip on the material outlet and fix it with the union nut. 5. Set the material pressure as follows (but max. 5.0 bar). Set the material pressure to max.
-
Page 9: Maintenance
Bedienungsanleitung Membranventil DV-5625-U / -SS Manual diaphragm valve DV-5625 Series VIEWEG 7 Maintenance 7.1 Cleaning Clean the valve regularly, especially if you are dosing material that is not intended to be used for hardening, or can lead to possible damage to parts that come into contact with... -
Page 10: Detail Drawings & Dimensions
Bedienungsanleitung Membranventil DV-5625-U / -SS Manual diaphragm valve DV-5625 Series VIEWEG After you have brought the new diaphragm to the correct distance (0.4 mm - see picture) to tighten the compressed air cylinder, turn the diaphragm with a screwdriver to the necessary position according to the following picture. -
Page 11: Exploded Drawing
Bedienungsanleitung Membranventil DV-5625-U / -SS Manual diaphragm valve DV-5625 Series VIEWEG 9 Exploded drawing 10 Parts and spare parts list DV-5625-U DV-5625-SS DV-5625-T Beschreibung Stk. DV-5625-U DV-5625-SS DV-5625-T Description piece Abb. V-0003 Einstellkappe V-0003 adjusting cap V-0011 O-Ring 15x2 V-0011... - Page 12 VIEWEG GmbH VIEWEG Dosier- und Mischtechnik Gewerbepark 13 85402 Kranzberg Germany Fon +49 8166 6784 -0 Fax +49 8166 6784 -20 info@dosieren.de www.dosieren.de...
