- Page 1 Leica DISTO D510 Leica DISTO D510 Leica DISTO X310 The original laser distance meter The original laser distance meter The original laser distance meter GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 2: Table Of Contents
Calculator - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13 Adjusting measuring reference/tripod - - - - - - - - - - - - - - - - - 14 Leica DISTO D510 792312 GlobalTestSupply www. -
Page 3: Instrument Set-Up
Navigation Function efficient manner. screen Return / Equal Add / Clear / Off Subtract Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 4: Basic Measuring Screen
Instrument Set-up Basic measuring screen Selection screen Status bar Page indicator Function / Settings Main line Active function Favorites Settings Help function Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 5: Pointfinder (Viewscreen)
Illumination Crosshair adjustment with navigation keys left and right Zoom (1x, 2x, 4x) with navigation keys up and down Active function Favorites Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 6: Operations
2 sec Stops permanent / minimum- maximum measuring. 8.532 m Used to measure room diagonals (maximum val- ues) or horizontal distance (minimum values) Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 7: Add / Subtract
Parallax errors occur when the pointfinder camera is used on close targets, with the effect that the laser appears dis- placed in the crosshair. In this case rely on the real laser dot. Leica DISTO D510 792312 GlobalTestSupply www. -
Page 8: Settings
Bluethooth Tilt calibration Reset Offset Tilt units Switch between the following units: Exit settings. Confirm setting. ± 90.0° 0.00 % ± 180.0° 0.0 mm/m 360.0° 0.00 in/ft Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 9: Distance Units
Beep ON/OFF Exit settings. To switch ON, repeat procedure. Digital level ON/OFF The digital level is displayed in the status line. To switch ON, Exit settings. repeat procedure. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 10: De-/Activate Keypad Lock
Select favorite favorite above the function. corresponding se- lection key. Illumination To save power re- duce bright- ness if not necessary. Exit settings. Confirm setting. Select brightness. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 11: De-/Activate Bluetooth Smart
For more details, see our homepage. Bluetooth standard V4.0) works together with all Bluetooth Smart Ready devices. All other Bluetooth devices do not support the energy saving Bluetooth Smart Module, which is integrated in the device. Leica DISTO D510 792312 GlobalTestSupply www. -
Page 12: Calibration Of Tilt Sensor (Tilt Calibration)
After 2 sec the device 180° goes back to the basic mode. 180° Turn the device horizontally by 180° and place it again on absolutely flat surface. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 13: Reset
An offset adds or subtracts a specified value automatically to or from all measurements. This func- tion allows tolerances to be taken into account. The offset icon is Exit settings. displayed. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 14: Functions
Select key on culator and can be used for fur- display. ther calculations. Ft/in fractions are converted into Meters. Confirm every key. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 15: Adjusting Measuring Reference/Tripod
(rear of the device). Confirm setting. Memory 12.208 m 6.554 m 23.889 m Use Up/Down Short cut Switch between navigation keys to measurements. show more re- sults. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 16: Measuring Single Distance
Smart Horizontal Mode 40.8 ° 5.204 m 0.032 m 4.82 7 m Aim laser at tar- get. (up to 360° and a transverse tilt of ±10°) Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 17: Height-Profile Measurement
Horizontal distance to distance and height is displayed for each fol- 2.042 m device lowing point. Exit function. 0.05 4 m Height difference to reference point (REF). Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 18: Area
Press + or - after starting the first measure- ment. Measure and add or subtract distanc- 20.276 m Circumference es. Finish with DIST. Measure 2nd length. 24.3 52 m Area Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 19: Volume
80.208 m Circumference 208.70 3 m Wall areas 24.224 m Ceiling/floor area Use Up/Down 78.6 94 m navigation keys to Volume show more re- sults. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 20: Triangular Area
The measuring time is increased. An icon in the status line shows if the function is active. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at:... -
Page 21: Inclination Tracking
Distance between both points vertical plane as the 2 measured show more re- points. The plane is defined of the sults. line between the 2 points. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 22: Height Tracking
/ Use Up/Down crosshair and does not need a reflec- navigation keys to tive laser target as only the inclination is show more re- measured. sults. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 23: Trapezium
Aim laser at upper Aim laser at 2nd point. point. 22.70° 78.257 m Trapezium area Use Up/Down 5.90 7 m navigation keys to show more re- sults. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 24: Stake Out
The function can be stopped the next stake out 0.625 m by pressing the CLEAR/OFF point is displayed. button. Approve value "b" 0.24 0 m and start meas- urement. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 25: Pythagoras (2-Point)
8.29 4 m navigation keys to horizontal measuring. show more re- For height measuring (vertical) it is more precise to use sults. a function with the incliantion measuring. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 26: Pythagoras (3-Point)
18.2 94 m navigation keys to rect horizontal measuring. show more re- For height measuring (vertical) it is more precise to sults. use a function with inclination measurement. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 27: Technical Data
198 g / 6.37 oz Long Range Mode Temperature range: - Storage -25 to 70 °C Calculator -13 to 158 °F - Operation -10 to 50 °C 14 to 122 °F Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 28: Message Codes
Hold the instrument Warranty coverage for the entire usage time than 10° without any transverse tilt. of the product according to Leica Geosys- Calibration mistake Make sure, the device is tems International Limited Warranty. Free of placed on a absolutely charge repair or replacement for all products horizontal and flat surface. -
Page 29: Permitted Use
• Aiming directly in the sun Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at:... -
Page 30: Electromagnetic Compatibility (Emc)
• Do not use the product in airplanes. Subject to change (drawings, descriptions and technical data) without prior notice. • Do not use the product near your body for extended periods. Leica DISTO D510 792312 GlobalTestSupply www. .com Find Quality Products Online at:... - Page 31 Quality Management and Quality Systems (ISO standard 9001) and Environ- mental Management Systems (ISO standard 14001). Total Quality Management - Our commitment to total customer satisfaction. Ask your local Leica Geosystems agent for more information about our TQM program. Pat. No.: WO 9427164, WO 9818019, WO 0244754, WO 0216964,...
