SPECIFICATIONS

SZ-ZA120
Power supply . . . . . . . . . . . . . 220-240Vac, 50/60Hz
Output power: RMS . . . . . . . . 120Wrms
Outputs : Speaker . . . . . . . . . 100V/ 8Ω / COM
Output: Line . . . . . . . . . . . . . . RCA signal output
Inputs . . . . . . . . . . . . . . . . . . . . 2-Mic XLR, 2 x mic/
Volume controls . . . . . . . . . . . Mic1, Mic2, mic/line
Equalizer: Bass / Treble . . . . . 120Hz ±10dB / 10kHz
Bluetooth version . . . . . . . . . . 4.0
Phantom power . . . . . . . . . . . +24V (MIC 1, MIC2
THD. . . . . . . . . . . . . . . . . . . . . . <0.5%
Dimensions . . . . . . . . . . . . . . . 488 x 345 x 100mm
Weight . . . . . . . . . . . . . . . . . . . 8.6KG
(IEC) or 24Vdc option
(screw terminals)
line jack, 2 x RCA line,
24V mute contacts
(1+2), line3, line4 /
(USB), master
±10dB
input
12
SZ-ZA240
Power supply . . . . . . . . . . . . . 220-240Vac, 50/60Hz
Output power: RMS . . . . . . . . 240Wrms
Outputs : Speaker . . . . . . . . . 4X100V /8Ω / COM
Output: Line . . . . . . . . . . . . . . RCA signal output
Inputs . . . . . . . . . . . . . . . . . . . . 2-Mic XLR, 2 x mic/
Volume controls . . . . . . . . . . . Mic1, Mic2, mic/line
Equalizer: Bass / Treble . . . . . 120Hz ±10dB / 10kHz
Bluetooth version . . . . . . . . . . 4.0
Phantom power . . . . . . . . . . . +24V (MIC 1, MIC2
THD. . . . . . . . . . . . . . . . . . . . . . <0.5%
Dimensions . . . . . . . . . . . . . . . 488 x 345 x 100mm
Weight . . . . . . . . . . . . . . . . . . . 9.8KG
(IEC) or 24Vdc option
(screw terminals)
line jack, 2 x RCA line,
24V mute contacts
(1+2), line3, line4 /
(USB), master
±10dB
input
