Router Mode; Update Time - 3Com SuperStack 3 3250 Implementation Manual

Table 6 RIP Parameters
RIP Parameter
*

Router Mode

Cost †

Update Time*

Send Mode
Receive Mode
Poison Reverse
Advertisement Address
* These RIP parameters apply to the entire Switch. All other parameters are defined per
interface.
† The Cost value cannot be altered, it is fixed at 1.
Router Mode
The available settings for router mode are as follows:
Disabled — The Switch ignores all incoming RIP packets and does not
generate any RIP packets of its own.
Enabled — The Switch broadcasts RIP updates and processes
incoming RIP packets.
Update Time
This Switch sends a RIP message every 30 seconds (by default) with both
the IP address and a metric (the distance to the destination from that
router) for each destination. You can modify the update time if needed to
adjust performance.
Send and Receive Modes
The following RIP send and receive modes are supported by the Switch:
Table 7 Send and Receive Modes
Send Mode
RIPv1
RIPv1Compatible
RIPv2
doNotSend
Default Value
disabled
1
30 seconds
RIPv1Compatible
RIPv1OrRIPv2
disabled
limited broadcast address (224.0.0.9)
Receive Mode
RIPv1
RIPv2
RIPv1OrRIPv2
doNotReceive
IP Routing Protocols 91
