Configuration Rules With Full Duplex - 3Com SuperStack 3 3250 Implementation Manual

Configuration Rules
with Full Duplex
A total network span of 325 m (1066 ft) is allowed in single-repeater
topologies (one hub stack per wiring closet with a fiber link to the
collapsed backbone). For example, a 225 m (738 ft) fiber link from a
repeater to a router or switch, plus a 100 m (328 ft) UTP link from a
repeater out to the endstations.
The Switch provides full duplex support for all its ports, excluding ports
operating at Gigabit speeds. Full duplex allows packets to be transmitted
and received simultaneously and, in effect, doubles the potential
throughput of a link.
With full duplex, the Ethernet topology rules are the same, but the Fast
Ethernet rules are:
Maximum UTP cable length is 100 m (328 ft) over Category 5 cable.
A 2 km (6562 ft) fiber link is allowed for connecting switch-to-switch,
or endstation-to-switch.
Configuration Rules for Fast Ethernet 101
