16 C 1: I
HAPTER NTRODUCING THE

Console Port

Matrix Port

S 3300 XM
WITCH
The console port allows you to connect a terminal and perform remote or
local out-of-band management. The console port uses standard null
modem cable and is set to auto-baud, 8 data bits, no parity and 1 stop
bit.
The matrix port allows you to:
Stack the Switch with another unit in the Switch 1100/3300 family
using a single Matrix Cable
Stack the Switch with up to three other units in the Switch 1100/3300
family, if one of the units has a Matrix Module installed
For more information about the role of the matrix port, see "Stacking
Units" on page 26.
