Tsubaki L Series Instruction Manual

Instruction Manual for Jaw Instruction Manual for Jaw- - - - flex coupling L Series Instruction Manual for Jaw Instruction Manual for Jaw
Thank you for purchasing a Jaw-flex Coupling. At fist, make sure the unit delivered matches your order and no
shortages exist in the parts provided. Any such shortages or other delivery errors must be reported immediately
to your distributor.
This manual should be considered an essential part of the Jaw-flex Coupling and remain with the coupling when
redistributed. To ensure safety, read all instructions thoroughly before installing or working on the equipment.
When using the product, read thoroughly the Instruction Manual and handle it correctly paying a sufficient attention to the
safety. Safety precautions in this manual are classified into two categories: "Warning" and "Caution".
Warning Warning Warning Warning
Death or serious injury may result from misusing the product.
Caution Caution Caution Caution
Minor or moderate injury, as well as damage to the product may result from misusing the product.
Notice that although categories under "Caution", subjects discussed may lead to serious results depending on the situation.
Make sure to follow the important contents written in "Warning" and "Caution".
And also the quality control is paid attention sufficiently. Preparing the unexpected accidents, enough consider the safety
action.
This manual should remain with the Jaw-flex Coupling at all time. To ensure safety, this manual should be kept as an easy
reference to anyone using the units at all time.
〔General〕
・Make sure to install a safety cover.
Injury may occur, when a hand or finger touch the product due to the rotating parts. Make sure to put the safety cover
to prevent the body from the rotating parts for preventing the danger.
Set a safety mechanism to stop the rotating parts immediately when the cover is lifted.
・Transporting, installing, operating, maintaining or inspecting must be carried out by skilled and professional engineers.
Injury or machine breakage may occur.
・When the coupling is used with vehicles that carry human, set a safety device at the device side for the safety purpose.
Bodily injury or machine breakage due to the runaway/falling may occur.
・When the coupling is used for the lifting/lowering device, set a safety device at the device side in order to prevent from
falling. Bodily injury or machine breakage due to falling may occur.
〔Transportation〕
・Never step under the product when it is elevated for transportation. Bodily injury due to the falling may occur.
〔Installation〕
・Wear the proper clothing and safety gear (safety glasses, gloves, safety shoes, etc.) when mounting or dismounting the
coupling.
・Make sure to turn off the power in advance, and prevent from the switch turning on suddenly.
・Make sure to tighten the bolts securely and prevent the bolts from loosening completely.
・Critical condition such as the breakage of the bolts may occur depending on the state of tightening of the bolts. Make
sure to tighten the bolts certainly.
〔Operation〕
・Never approach or contact to the rotating parts (coupling, shaft, etc.) during operation. Getting into the machine or
bodily injury may occur.
〔Maintenance and inspection〕
・Never approach or contact to the rotating parts (coupling, shaft etc.) when maintaining or inspecting during operation.
Getting into the machine or bodily injury may occur.
・ Make sure to turn off the power in advance, and prevent from the switch turning on suddenly. In addition, make sure to
stop the rotation of the drive or driven machine certainly.
Sintered Hub type/ Aluminum Hub type Sintered Hub type/ Aluminum Hub type Sintered Hub type/ Aluminum Hub type Sintered Hub type/ Aluminum Hub type
Cautions for Cautions Cautions Cautions
Warning Warning Warning Warning
flex coupling L Series flex coupling L Series flex coupling L Series
for safety for for safety safety safety
-1-
