Tsubaki MZEU Series Installation And Maintenance  Instruction

Tsubaki MZEU Series Installation And Maintenance Instruction

Cam clutch

Advertisement

Quick Links

MZEU30(K), MZEU35(K), MZEU40(K) ,MZEU45(K), MZEU50(K) MZEU60(K), MZEU70(K),
Thank you for choosing Tsubaki E&M products.
Before installing or working on the product, confirm it is the correct size by checking its label and make sure you have the complete set of
arts. If any part is missing, contact your distributor immediately.
This manual should be considered an essential part of the unit and remain with the unit when redistributed.
Your Cam Clutch is a high quality, sophisticated unit which should be handled by experienced engineers only.
For safety purposes, make sure this manual is easily accessible by the user at all times.
To ensure safety and optimal performance, carefully read this instruction manual in its entirety.
WARNING
1. Guards must be provided on all chain and sprocket installations in
accordance with provisions of ANSI/ASME B15.1 - 2000
"Safety Standards for Mechanical Power Transmission Apparatus," and
ANSI/ASME B20.1 - 2012 "Safety Standards for Conveyors and Related
Equipment," or other applicable safety standards. When revisions of
these standards are published, the updated edition shall apply.
2. Always lock out the power switch before installing, removing, lubricating
or servicing a system which uses PTUC product.
3. When connecting or disconnecting PTUC products, eye protection is required.
Wear safety glasses, protective clothing, gloves and safety shoes.
4. Improper installation or mounting, as well as operating conditions and maintenance,
can affect the performance of a cam clutch. The cam clutch should be inspected regularly.
"PTUC is used by U.S. Tsubaki to designate "Power Transmission Unit Components."
PTUC products include Cam Clutch DISCO, POWER-LOCK
HF Drive, Shock Damper, Power cylinder
other like products manufactured by/for Tsubaki.
Cam Clutch Installation and Maintenance Instruction
MZEU80(K), MZEU90(K), MZEU100(K), MZEU130(K), MZEU150(K)
Death or serious injury may result from misuse, improper installation and/or improper maintenance of
this product. Please refer to the detailed instructions provided in this manual for installation and
maintenance specifications.
USE CARE TO PREVENT INJURY
COMPLY WITH THE FOLLOWING TO
AVOID SERIOUS PERSONAL INJURY:
MZEU Series
SAFETY
WARNING
, Shock Relay, Gearmotor,
TM
, Couplings, SCR variable speed motor and
TSUBAKI E&M CO.
- 1 -
