E-6 Digital Control Surface
TECHNICAL MANUAL
600 Industrial Drive, New Bern, North Carolina, USA 28562

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-6 and is the answer not in the manual?

Questions and answers

Related Manuals for Wheatstone Corporation E-6

Summary of Contents for Wheatstone Corporation E-6

  • Page 1 E-6 Digital Control Surface TECHNICAL MANUAL 600 Industrial Drive, New Bern, North Carolina, USA 28562...
  • Page 2 E-6 Digital Control Surface Technical Manual - 1st Edition E-6 Digital Control Surface Technical Manual - 1st Edition E-6 Digital Control Surface Technical Manual - 1st Edition E-6 Digital Control Surface Technical Manual - 1st Edition E-6 Digital Control Surface Technical Manual - 1st Edition ©2007 Wheatstone Corporation...

  • Page 3: Table Of Contents

    CUE Switch ....................... 2-5 TB BUS- Switch ......................2-5 Fader ......................... 2-6 Channel ON Switch ....................2-6 Channel OFF Switch ....................2-6 Channel Status Buttons Display ................2-6 page Contents – 1 E-6 / Apr 2007 E-6 / Nov 2009...
  • Page 4 View/Processor Button .................... 3-17 Switched Meters ...................... 3-18 Route ........................3-19 Timer Section ......................3-20 Time of Day Clock ....................3-20 Programmable Buttons .................... 3-21 VDIP Settings ......................3-23 Machine Logic ......................3-25 page Contents – 2 E-6 / Apr 2007...
  • Page 5 C O N T E N T S Dynamics Processing Controls ................3-26 Using the Embedded E-6 GUI ................3-26 EQ Settings ......................3-27 Filter ......................... 3-27 Low and High Shelving ..................3-27 Compressor Settings ..................3-28 Expander Settings ....................3-29 Side Bar ......................
  • Page 6 Modifying The Options Text File ................A-6 A Simple Example From The File ................A-7 A Second Example ....................A-8 An Example File - Complete ................... A-9 Appendix 3 Replacement Parts List ............A-13 page Contents – 4 E-6 / Apr 2007...
  • Page 7 Control Surface Placement ............1-3 Power Supply ................1-4 Failsafe Dual Redundant Supply ................1-5 Energizing ....................... 1-5 I/O Connections ................1-6 Getting Started ................1-8 Surface Software Version ............1-8 page 1 – 1 E-6 / Apr 2007 E-6 / Nov 2009...

  • Page 8: Introduction

    Introduction Designed to integrate flawlessly with the E-series Satellite digital audio network router, the E-6 control surfaces allow you to easily create large- or small- platform- based systems that are exceptionally user-friendly and flexible. The E-6 control surface has major market features: event recall, both bus-minus and mix-minus, and four aux mixes—all with dedicated talkback systems.

  • Page 9: Control Surface Placement

    Cutout dimensions (in inches) are shown in the drawings below for 5 available frame sizes. Do not connect the E-6 control surface to its power supply (and do not connect the power supply to the AC power line) until instructed to do so.

  • Page 10: Power Supply

    Rear view of the PSU-1 rackmount power supply If failsafe redundant sup- The E-6 control surface is powered by a Wheatstone Model PSU-1 plies have been ordered, rackmount power supply. This unit occupies two 19” wide rack spaces you will be installing two PSU-1 units.

  • Page 11: Failsafe Dual Redundant Supply

    BOTH rackmount supplies powered up and connected to their associ- ated equipment. Energizing Assuming the E-6 control surface mainframe is properly placed, and its PSU-1 power supply (or supplies) correctly rackmounted and connected to the control surface, you may now energize the rackmount power supply by plugging it into the AC mains.

  • Page 12: I/O Connections

    G E N E R A L I N F O R M A T I O N I/O Connections All user wiring to and from the E-6 control surface is made via connectors located on the control surface’s rear panel. Two 5-pin male connectors at the center of the control surface’s rear are for power...
  • Page 13 G E N E R A L I N F O R M A T I O N page 1 – 7 E-6 / Apr 2007 E-6 / Nov 2009...

  • Page 14: Getting Started

    G E N E R A L I N F O R M A T I O N Getting Started The E-6 control surface comes with a E-6 Embedded Graphical User Interface (GUI) program, intended to be straightforward in use, controlling and displaying graphics, production tools, and set up screens.
  • Page 15 LED Readout ......................2-5 CUE Switch ......................2-5 TB BUS- Switch ...................... 2-5 Fader ........................2-6 Channel ON Switch ....................2-6 Channel OFF Switch ....................2-6 Channel Status Buttons Display ................2-6 page 2 – 1 E-6 / Apr 2007...

  • Page 16: Chapter 2 - Input Panel (Ipe-6)

    I N P U T P A N E L Input Panel (IPE-6) Controls and Functions Each input panel of the E-6 digital audio control surface has four identical strips representing four input channels. Input Sources Each input panel controls four stereo sources.

  • Page 17: Programmable Buttons

    Set button on the screen. If your choice was “Take A Preset” then the PROCESSOR PRESETS screen pops up when you click the Set button to allow you to choose the desired preset. page 2 – 3 E-6 / Apr 2007...

  • Page 18: Channel Mode Indicator

    I N P U T P A N E L Channel Mode Controls and Indicators MODE selection is set in the Embedded E-6 GUI using the mouse pad, located in the center of the master panel, to control the mouse pointer on the VGA screen for system software navigation.

  • Page 19: Surround Phase System

    LFE - slider controls level of signal sent to subwoofer channel. WIDTH - slider controls an effect that changes the apparent distance between the speakers - applies to stereo signals only. page 2 – 5 E-6 / Apr 2007...

  • Page 20: Phase

    The TB BUS- switch routes the TB BUS audio, typically the operator’s microphone, to the BUS MINUS output for that channel, allowing the operator to talkback to the talent hearing that BUS MINUS signal. page 2 – 6 E-6 / Apr 2007...

  • Page 21: Fader

    Operator should be made aware that logic associated with a signal will not act as expected when the logic lock indicator is ON. page 2 – 7 E-6 / Apr 2007...
  • Page 22 Program Output Select ..................3-13 External Source Select ..................3-13 Mix-Minus ......................3-13 AUX Sends ...................... 3-13 Headphone Level Control................3-13 E6 Monitor Configuration..................3-14 Enter Button......................3-14 Help Button ......................3-14 page 3 – 1 E-6 / Apr 2007...
  • Page 23 Programmable Buttons ..................3-21 VDIP Settings ....................... 3-23 Machine Logic ....................... 3-25 Dynamics Processing Controls ................3-26 Using the Embedded E-6 GUI ................3-26 EQ Settings ......................3-27 Filter ......................... 3-27 Low and High Shelving ..................3-27 Compressor Settings ..................3-28 Expander Settings ....................

  • Page 24: Chapter 3 - Master Panel (Mne-6)

    C O N T R O L P A N E L Master Panel (MNE-6) Controls and Functions The E-6 digital audio control surface is equipped with one MASTER panel. This panel contains numerous controls, in- cluding INPUT SOURCE select, PAN,...
  • Page 25 C O N T R O L P A N E L There are two more options to select the source for an input channel via the E-6 Embedded GUI software. • With any input SET button pressed, pressing the INPUT SOURCE knob pops up a list of available sources for that channel.

  • Page 26: Aux Buses

    All adjustments can be saved to a channel, a source, an event, headphones, or a preset. The VIEW, NEW, NAME buttons are described later in the manual (see Side Bar on page 3-31). page 3 – 5 E-6 / Apr 2007...

  • Page 27: Mxm Assign

    There are several mix-minus options that can be programmed. Press the OPTIONS button on the MNE-6 panel and select MIX-MINUS from the pop-up list to bring up the E6 “Mix Minus Config” screen. page 3 – 6 E-6 / Apr 2007...
  • Page 28 If that signal is then brought up on a different channel having different MXM settings, the new channel’s MXM settings will then be applied to that signal. page 3 – 7 E-6 / Apr 2007...
  • Page 29 “X” in the upper right corner of the window, you will be prompted to save your changes. You can choose to save or not to save. page 3 – 8 E-6 / Apr 2007...

  • Page 30: Mxm Talkback

    CUE is sent to the left side. The EQ switch, when activated, will send an equal- ized signal to the headphone. See later in the manual for making EQ adjustments. page 3 – 9 E-6 / Apr 2007...

  • Page 31: Monitors

    Pressing either of the two external (EXT1 or EXT2) switches allows the operator to pick up the associated external input (useful for such as tape recorders or air returns) to listen to. page 3 – 10 E-6 / Apr 2007...

  • Page 32: Mix-Minus

    NOTE: If the Control Room is muted and you turn the level control all the way up, then remove the condition that has the Control Room muted, the sound in the Control Room speakers will suddenly be VERY LOUD! page 3 – 11 E-6 / Apr 2007...

  • Page 33: Studio Section

    The TB button lets the operator’s microphone signal interrupt the normal feed to the studio speakers. STUDIO Level Control The STUDIO level control determines the overall loudness of the signal being monitored as it appears in the Studio speakers. page 3 – 12 E-6 / Apr 2007...

  • Page 34: Headphone Section

    Pressing any of the four AUX SEND switches allows the operator to monitor the AUX send signal. HEADPHONE Level Control The HEADPHONE level control determines the overall loudness of the headphone output signal. page 3 – 13 E-6 / Apr 2007...

  • Page 35: E6 Monitor Configuration

    The headphone, control room, and studios outputs are normally subject to the control surface’s muting and cue interrupt circuits. However, cue interrupt may be defeated via the Embedded E-6 GUI. Press the OPTIONS button, choose “Monitor Config”, and set the defeat option for headphone, control room, and studios.

  • Page 36: Events

    Viewing Event Choices Pressing the VIEW EVENT button allows the operator to view the control surface’s event choices via the Embed- ded E-6 GUI. This function can be password protected. Loading an Event from the EVENT CHOICES screen, highlight the de- sired event and press Load.

  • Page 37: Control Modes

    C O N T R O L P A N E L Control Modes The E-6 control surface is operated in one of five modes: Intern, Operator, Production, Engineering, and Factory. Factory mode is reserved for factory use only. Engineering mode, by default, allows the user to perform all surface functions.

  • Page 38: View/Processor Button

    The operator can manage E-6 presets via the Embedded E-6 GUI. Press the OPTIONS button, choose “Presets”, and APPLY (DELETE) presets to (from) CHANNEL ASSOCIATIONS and SOURCE ASSOCIATIONS lists.

  • Page 39: Switched Meters

    Peak and Average readouts. You can choose only Peak or Aver- age reading via the Embedded E-6 GUI. Press the OPTIONS button, choose “Meter Options”, and choose the desired readout from the Meter Mode pop-up list.

  • Page 40: Route

    • When no SET button is pressed, it opens a screen showing a full Matrix List of input sources and loca- tions for quick source selection on a fader, or for matching other connections within the system. page 3 – 19 E-6 / Apr 2007...

  • Page 41: Timer Section

    Releasing the button will then display the current count. Time of Day Clock The main Embedded E-6 GUI screen includes the digital and analog displays of a time of day clock. To set the time on this clock you run a Wheatstone utility program, WSTimeSet.exe, on a network computer.

  • Page 42: Programmable Buttons

    Network System manual for details. Some of the spare button programming can be done via the Embedded E-6 GUI. Press the OPTIONS button and choose “Programmable Buttons” to display the “E6 Spare Buttons” form. You will see a separate line on the form for each of the 14 buttons;...
  • Page 43 C O N T R O L P A N E L • Software Controlled - in this mode the button’s function is set up by the Embedded E-6 GUI, as described below - the LED is controlled by the surface and is on while the button is pressed and off when released •...

  • Page 44: Vdip Settings

    EFS—This function causes the channel to be OFF when the fader is fully down or ON when the fader is brought up from the fully down position. The ON and OFF switches can still control the channel. page 3 – 23 E-6 / Apr 2007...
  • Page 45 Bus Minus Follow Channel ON—Sets the input signal sent to the Bus Minus system to follow the channel ON switch. If this box is unchecked the signal is sent regardless of the channel ON status. page 3 – 24 E-6 / Apr 2007...

  • Page 46: Machine Logic

    Machine Logic The operator can select the surface’s start/stop logic options via the Embedded E-6 GUI. Press the OPTIONS button and choose “Machine Logic” to display the “E6 Machine Logic Options” form. The purpose of this option is to allow the privileges operator to...

  • Page 47: Dynamics Processing Controls

    C O N T R O L P A N E L Dynamics Processing Controls CHANNEL BUTTONS Using the Embedded E-6 GUI Click on the EQ button on the right-bottom corner of the monitor screen to display the Dynamics Processing Controls for the selected channel. This screen allows full control of 4-Band Parametric Equalizer, Expander, and Compressor settings.

  • Page 48: Eq Settings

    The low shelver (activated by the SLF switch below the LO WIDTH slider) at the lower end of its range will enable specific kick-drum or bass guitar elements of a source to be balanced with respect page 3 – 27 E-6 / Apr 2007...

  • Page 49: Compressor Settings

    “Baxandall” style tone control, noted for its ease in rapid correction of tonal imbalance. Compressor Settings The compressor algorithm used in the E-6 is designed to: - prevent really ghastly noises from being achieved too easily; - allow smooth, inaudible, and unobtrusive level control on un- even sources;...

  • Page 50: Expander Settings

    The gain-reduction reduces as the threshold is approached, and there is none above the threshold. The controls are: EXP — A switch that allows the expander to be enabled and disabled. page 3 – 29 E-6 / Apr 2007...
  • Page 51 “disappear” in the context of a mix; the whole gating sound, especially surprisingly its opening, is less obvious with shallower depth. Sometimes the “Surprise!” element is required, though, for effect. page 3 – 30 E-6 / Apr 2007...

  • Page 52: Side Bar

    Clicking on the VIEW button display the “Processor Presets” form with list of the available presets. Clicking on the New button displays the “New Preset” form and virtual keyboard that you can use to name a new preset. page 3 – 31 E-6 / Apr 2007...
  • Page 53 Source and Destination Displays The SOURCE display shows the selected channel’s source name and input fader number. Assign the selected source to any available destinations using up/ down scroll arrows in the DESTINATION display. page 3 – 32 E-6 / Apr 2007...

  • Page 54: Optional Glass E Interface

    E. The surface presets, system X-Y access, system programming and configuration are password protected. To make a connection between the Embedded E-6 GUI and the Glass-E software press the OPTIONS button and choose “Glass E Interface” to display the “E6 Glass E Interface Options” form. Enter a Port Number (the default is 49152), a User Name and Password, and click “OK”.
  • Page 55 C O N T R O L P A N E L page 3 – 34 E-6 / Apr 2007...
  • Page 56 “CAT5” RJ-45 - Mixer Link Connector ..............4-4 “HEADPHONE” - Headphone Connector ............... 4-4 Typical Ethernet Cable .............. 4-5 Typical Crossover Cable ............4-5 HC-3 Pinouts Drawing ............... 4-6 page 4 – 1 E-6 / Jan 2008 E-6 / Apr 2007...

  • Page 57: Overview

    Keyboard, floppy controller, and video ports are for factory use only. The purpose of the host controller is to provide control of the E-6 control surface. The HC-3 communicates to the XPoint Configuration PC via TCP/ IP over Ethernet through a standard ethernet hub or switch. It also communi- cates to the Bridge Router system via a special mixer link connection.

  • Page 58: Mixer Link Wiring

    Position 4 of SW1 must be in the on position in order to activate the CAT5 mixer link connections. SW2 - CPU Reset This momentary pushbutton switch allows the host controller to be reset without powering down the system. page 4 – 3 E-6 / Jan 2008 E-6 / Apr 2007...

  • Page 59: Hook-Ups

    Pin 9 – HDPN LT LO Pin 7 – HDPN RT HI Pin 8 – HDPN RT SH Pin 3 – HDPN RT LO Pin 1 – N/C Pin 2 – N/C Pin 6 – N/C page 4 – 4 E-6 / Apr 2007...
  • Page 60 RXD - Orange Green RXD + TXD + White/Green White/Orange RJ-45 RJ-45 Plug Blue Blue Plug White/Blue White/Blue RXD - TXD - Green Orange White/Brown White/Brown Brown Brown SED FOR MIXER LINK CONNECTOR page 4 – 5 E-6 / Apr 2007...
  • Page 61 RXD - RXD - LN LED LK LED "HEADPHONE" Female DB-9 These are line level inputs 5 4 3 2 1 to the internal amplifiers that feed the surface’s head- phone jack. page 4 – 6 E-6 / Apr 2007...
  • Page 62 MNE-6 Master Panel Switch Card Schematic ......................... 5-7 Load Sheet ......................5-11 HC-3 Host Controller Card Schematic ........................ 5-12 Load Sheet ......................5-16 PSU-1 Power Supply Schematic ........................ 5-17 Load Sheet ......................5-18 page 5 – 1 E-6 / Apr 2007...
  • Page 63 DATE DRAWN 1-30-07 600 Industrial Drive New Bern, NC 28562 CHECKED __________________________ SWITCH LED DRIVE LOW ISSUED SIZE FSCM NO. DWG. NO. 84S0170-1 W# 700886 IPE-6 PCB 1 OF 2 SCALE SHEET page 5 - 2 E-6 / Apr 2007...
  • Page 64 DATE MDL_CLK DRAWN FDR_2.5REF 1-30-07 600 Industrial Drive New Bern, NC 28562 FADER 1 CHECKED DS46 ISSUED SIZE FSCM NO. DWG. NO. 84S0170-2 W# 700886 IPE-6 PCB 2 OF 2 SCALE SHEET page 5 - 3 E-6 / Apr 2007...
  • Page 65 S C H E M A T I C D R A W I N G S IPE-6 4 Inputs Panel Switch Card - Load Sheet page 5 – 2 page 5 – 4 E-6 / Apr 2007...
  • Page 66 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 600 Industrial Drive 10-25-06 New Bern, NC 28562 CHECKED SIZE FSCM NO. DWG. NO. 84S0172 ISSUED W# 700888 SCALE ONSE-6A PCB SHEET 1 OF 1 page 5 - 5 E-6 / Apr 2007...
  • Page 67 S C H E M A T I C D R A W I N G S ONSE-6 4 Inputs Panel On/Off Switch Load Sheet page 5 – 3 page 5 – 6 E-6 / Apr 2007...
  • Page 68 DRAWN WWP/SA 3-26-07 600 Industrial Drive __________________________ New Bern, NC 28562 SWITCH LED DRIVE LOW CHECKED ISSUED SIZE FSCM NO. DWG. NO. 84S0171-1 W# 700887 SCALE MNE-6B PCB SHEET 1 OF 4 page 5 - 7 E-6 / Apr 2007...
  • Page 69 FDR_2.5REF APPROVALS DATE DRAWN AD_ST2 SA/WWP 3-26-07 600 Industrial Drive New Bern, NC 28562 CHECKED 100K ISSUED SIZE FSCM NO. DWG. NO. 84S0171-2 W# 700887 MNE-6B PCB 2 OF 4 SCALE SHEET page 5 - 8 E-6 / Apr 2007...
  • Page 70 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN SA/WWP 3-26-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 84S0171-3 W# 700887 MNE-6B PCB 3 OF 4 SCALE SHEET page 5 - 9 E-6 / Apr 2007...
  • Page 71 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN SA/WWP 3-26-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 84S0171-4 W# 700887 MNE-6B PCB 4 OF 4 SCALE SHEET page 5 - 10 E-6 / Apr 2007...
  • Page 72 MNE-6 Master Panel Switch Card - Load Sheet page 5 – 11 E-6 / Apr 2007...
  • Page 73 5 - 12 E-6 / Apr 2007...
  • Page 74 5 - 13 E-6 / Apr 2007...
  • Page 75 5 - 14 E-6 / Apr 2007...
  • Page 76 5 - 15 E-6 / Apr 2007...
  • Page 77 HC-3 Host Controller Card - Load Sheet page 5 – 16 E-6 / Apr 2007...
  • Page 78 - SA UR US - Sergey Averin - APPROVALS DATE 600 Industrial Drive DRAWN 2-3-06 New Bern, NC 28562 CHECKED SIZE FSCM NO. DWG. NO. 00S0034 ISSUED W# 700828 PSU-1B PCB 1 OF 1 SCALE SHEET page 5 - 17 E-6 / Apr 2007...
  • Page 79 S C H E M A T I C D R A W I N G S PSU-1 Power Supply Load Sheet page 5 – 4 page 5 – 18 E-6 / Apr 2007...
  • Page 80 Modifying The Options Text File ................A-6 A Simple Example From The File ................A-7 A Second Example ....................A-8 An Example File - Complete ..................A-9 Appendix 3 Replacement Parts List .............. A-13 page A – 1 E-6 / Apr 2007...
  • Page 81 A P P E N D I C E S Appendix 1 Contents Control Surface Clock ..............A-3 Setting the Time ......................A-3 Update Options ......................A-3 Synchronize ......................A-3 Battery Backup ......................A-4 page A – 2 E-6 / Apr 2007...

  • Page 82: Control Surface Clock

    A P P E N D I C E S Control Surface Clock The main Embedded E-6 GUI screen includes the digital and analog displays of a time of day clock. Setting the Time Setting the time of the control surface’s...

  • Page 83: Battery Backup

    (it will do this for 3 to 4 weeks). To activate battery backup of the control surface’s clock simply pull out the yellow strip from the HC-3 board, as shown on the picture below. page A – 4 E-6 / Apr 2007...
  • Page 84 Options Text File ................A-6 Introduction ....................... A-6 Modifying The Options Text File ................A-6 A Simple Example From The File ................A-7 A Second Example ....................A-8 An Example File - Complete ..................A-9 page A – 5 E-6 / Apr 2007...

  • Page 85: Options Text File

    Options Text File Introduction There are a number of operational features on the E-6 surface that are controlled by the contents of the Options Text File (E6_OPTS.TXT) that resides on the surface's flash drive. In order to configure these features it is necessary to modify this file.

  • Page 86: A Simple Example From The File

    The edited line must follow the established syntax precisely or the surface may not behave as expected. page A – 7 E-6 / Apr 2007...

  • Page 87: A Second Example

    You may have fewer or greater modes available depending on the surface model and vintage. In any event you can select the same or a different mode from the available modes for each programmable button on the surface. page A – 8 E-6 / Apr 2007...

  • Page 88: An Example File - Complete

    // ? is the mode (default = 0)... 0 = Post Fader, Post ON (default mode) 1 = Pre Fader, Post ON 2 = Post Fader, Pre ON 3 = Pre Fader, Pre ON page A – 9 E-6 / Apr 2007...
  • Page 89 3 = Momentary, Button is active when held down, LED controlled by DIO 4 = Automation, Button & LED are controlled by automation interface 5 = Preset Select, Button selects pre-configured preset, LED controlled by Surface SPARE1:2 SPARE2:2 SPARE3:2 SPARE4:2 SPARE5:2 page A – 10 E-6 / Apr 2007...
  • Page 90 // ? 0 = (default) No Mix Minus level control on Monitor card. 1 Monitor card has Mix Minus control. MXM_LVL_CTL:0 // Syntax: INPUT_GAIN_SLIDERS:? // ? 0 (default) = No input gain sliders, 1 = Input gain sliders. INPUT_GAIN_SLIDERS:0 VGA_CONTROLS:1 page A – 11 E-6 / Apr 2007...
  • Page 91 // 0xfff0c0 (default) = Color for selected readout background. READOUT_SELECTED:0xccff66 // Syntax: READOUT_NTEXT:0xRRGGBB // 0x000000 (default) = Color for readout text. READOUT_NTEXT:0xfa9007 // Syntax: READOUT_STEXT:0xRRGGBB // 0x000000 (default) = Color for selected readout text. READOUT_STEXT:0x000000 DEBUG_FLAGS:0x00000001 page A – 12 E-6 / Apr 2007...

  • Page 92: Appendix 3

    Replacement Parts List .............. A-14 For the most part there are no user-replaceable parts in the E-6 control surface. Exceptions are those controls and components that in the course of normal use may need maintenance (i.e., faders, pots, ON switches, etc.). A complete list of available components is shown on the next page.
  • Page 93 A P P E N D I C E S REPLACEMENT PARTS — E-6 CONTROL SURFACE COMPONENT DESCRIPTION WS P/N IPE-6 PANEL COMPLETE INPUT PANEL "009500" MNE-6 PANEL COMPLETE MASTER PANEL "009501" "009529" BK-E6 PANEL BLANK PANEL IPE-6 LOADED CARD INPUT PANEL LOADED CARD ASSEMBLY "009515"...
  • Page 94 A P P E N D I C E S REPLACEMENT PARTS — E-6 CONTROL SURFACE COMPONENT DESCRIPTION WS P/N ENCODER 11mm ROTARY ENCODER WITH THREADED BUSHING "560002" ENCODER KNOB 15MM GRAY COLLET KNOB FOR 1/8" SHAFT "520022" ENCODER KNOB 11MM BLACK PUSH-ON KNOB "520105"...
