Enable or disable the port
■
Enable or disable flow control
■
Configure the speed duplex settings
■
Set the priority of the port
■
Accessing the Interface Without Using
Discovery
The Discovery application works by automatically
detecting the IP address that is assigned to the Switch,
and then using that address to connect to the Web
interface. If you know the Switch's IP address, you can
access the Web interface without using Discovery.
This section describes how to access the interface
directly, without using Discovery.
If you do not configure the Switch's IP address settings,
it will perform auto IP configuration to assign an IP
address to itself. For more information, refer to
"Automatic IP Configuration" on page 29.
To determine the IP address that the Switch will assign
to itself during auto IP configuration, check the sticker
on the base of the Switch. This sticker contains the
MAC address and default IP address of the Switch.

DHCP Assigned IP Address

If you set the IP address mode to DHCP, check the
DHCP server for the IP address that is assigned to the

Accessing the Interface Without Using Discovery

Switch, and then use that IP address to access the Web
interface.
For example, if the DHCP server assigned the IP address
192.168.0.123 to the Switch, start your Web browser,
and then type http://192.168.0.123.

Manually Assigned (Static) IP Address

If you assigned a static IP address to the Switch, you
need to use that IP address to access the Web interface
the next time you want to configure the Switch.
For example, if you assigned the Switch the IP address
192.168.0.123, start your Web browser, and then type
http://192.168.0.123.
25
