24 C W
ONNECTING TO THE
Table 2 lists the available items on the menu.
Table 2 Available Menu Items
Menu Item Description
Summary Provides a summary of the Switch's
basic settings and versions of current
components
Password Allows you to change the administrator
password
IP Setting Allows you to configure the IP address
settings of the Switch
Port Configuration Allows you to configure the Switch's
port settings
VLANS Allows you to create VLAN groups, add
port members, and specify how VLAN
tagging is used
Link Aggregation Allows you to set up and maintain
trunk membership for port groups
Statistics Provides a summary of traffic statistics
for all ports.
Port Mirroring Allows you to perform port traffic
monitoring on the Switch. To monitor
a port, you will also need a network
analyzer.
Cable Diagnostics Allows you to detect and resolve cable
issues
(continued)
I
EB NTERFACE
System Tools Allows you to perform various system
maintenance tasks, such as upgrading
the firmware, resetting the Switch,
backing up and restoring configuration
Support Displays 3Com contact information
and describes how to use the online
help system
Log Out Allows you to securely log off the Web
interface

Buttons

Depending on the screen that is currently displayed, the
following buttons may appear:
Apply – Click to save and apply any changes that
■
you have made
Cancel – Click to discard any unsaved changes
■
Help – Click to display the context-sensitive help
■
information for the screen that is currently displayed.
The help pages provide information on the tasks that
you can perform on each screen.

Device Mimic

At the bottom of each screen is an image of the
Switch's front panel, which indicates ports that are
currently in use.
To configure a port, click the port on the image. This
takes you to the Basic Port Configuration tab, where
you can:
Assign a name (or label) to the port
■
