38 C S
ONFIGURING THE WITCH
The Status column refers to the speed and duplex mode
of the trunk members. To change the speed and duplex
mode of the trunk, click the Modify/Delete tab.
Figure 16 Trunking Membership Screen

Modifying Trunk Settings and Deleting a Trunk

Use the Modify/Delete tab to modify the trunk name
and configure flow control and duplex settings of the
trunk.
To modify trunk settings:
1 On the Modify/Delete tab, modify any of the following
settings:
Name — Allows you to label an interface (up to
■
characters)
Flow Control — Allows automatic or manual
■
selection of flow control.
Speed Duplex – Allows auto-negotiation to be
■
enabled or disabled. When autonegotiation is
disabled, you can force the settings for speed,
duplex mode, and flow control.
Click Apply.
2
To delete a trunk, click the corresponding Delete check
box, and then click Apply.
Figure 17 Trunking Screen

Viewing the Trunk Summary

If you want to view a summary of the trunk settings,
click the Summary tab.
