Introduction To The Switch 4210 Family Non-Pwr Models - 3Com 4210 Getting Started

14 C 1: P
HAPTER RODUCT
Introduction to the
Switch 4210 Family
Non-PWR Models
Switch 4210 9-port
I
NTRODUCTION
Table 5 The 1000 Mbps uplink port status LED on 4210 PWR models
LED
1000 Mbps uplink port
active LED
This section describes each Switch 4210 Family model.
Front panel
The Switch 4210 9-port model provides eight 10/100Base-TX autosensing
Ethernet ports, one 10/100/1000Base-T autosensing Ethernet port, one
100/1000Base-X SFP port, and one Console port. The SFP port and the
10/100/1000BASE-T autosensing Ethernet port form a Combo port. For the
Combo port, either the SFP port or the 10/100/1000BASE-T Ethernet port can be
used at a time.
Figure 10 shows the front panel of the Switch 4210 9-port model.
Figure 10 The Switch 4210 9-port model's front panel
(1) 10/100Base-TX autosensing port Speed LED (green)
(2) 10/100Base-TX autosensing port
(4) 10/100/1000Base-T autosensing port
(6) 100/1000Base-X SFP port
(8) Power LED (PWR)
.
Mark on the
panel Status
ACT BLINKING
OFF
( 1 ) ( 2 )
( 8 ) ( 7 )
Description
The port is in the active state and
there is traffic on the port.
The port is in the active state but
there is no traffic on the port.
( 3 ) ( 4 )
( 7 ) ( 6 )
(3) Combo port Speed LED (green)
(5) Console port
(7) Link/Act LED (green)
( 5 )
