LM-HP-S
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the
packaging and maintains the orientation of the product in the packaging; then inspect the product closely to
determine whether it sustained damage during transport. If damage is discovered during the inspection,
immediately record a complete description of the damage on the bill of lading. If the product is
undamaged, discard the packaging.
Notes:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the
product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:
a) Instructions in this manual; or b) information provided on labels affixed to the product.
Table of Contents:
Signal Words.............................................................................................................................................. 2
Safe Use Recommendations......................................................................................................................... 2
Labeling Diagram........................................................................................................................................ 2
Fig. 1: Lm-Hp Parts Diagram, Dimensions, And Bill Of Materials ........................................................................... 3
Installation Instructions................................................................................................................................. 3
Use Instructions.................................................................................................................................. ......... 3
Inspections............................................................................................................................................3 - 4
Maintenance.............................................................................................................................................. 4
Limited Warranty......................................................................................................................................... 4
Copyright 2014 Vestil Manufacturing Corp.
Rev. 2/4/2016
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
www.vestilmfg.com
L
ERIES
OAD
I
NSTRUCTION
LM-HP, MANUAL.doc
V
M
ESTIL
ANUFACTURING
Fax: (260) 665-1339
H
F
OOK
ORK
M
ANUAL
C
ORP
e-mail:
sales@vestil.com
A
TTACHMENTS
Page 1 of 4
.
