Solar Wall Security Light - 90 LED
Please read these instructions carefully before use and retain for future reference.
IMPORTANT SAFETY INFORMATION
•
Avoid locations of high temperature or humidity.
•
The lamp is rated at IP65 for external use.
WHAT'S INCLUDED
•
Lamp assembly.
•
User manual.
•
Pack of screws and wall plugs.
POSITIONING
•
The lamp is suitable for mounting on plasterboard, wood or masonry surfaces.
•
It should be mounted in a position of maximum sunlight for optimum charge of the
internal battery.
•
Before drilling any fixing holes, check that there are no hidden obstructions behind
the mounting surface such as pipes or cables.
INSTALLATION
•
Offer the lamp to the surface and mark the location of the
fixing holes.
•
Drill the wall if required, fit the wall plugs then attach the
lamp using the screws provided.
Model: PEL01358
1
Advertisement
Table of Contents
Related Manuals for Pro-Elec PEL01358
Summary of Contents for Pro-Elec PEL01358
- Page 1 Solar Wall Security Light - 90 LED Model: PEL01358 Please read these instructions carefully before use and retain for future reference. IMPORTANT SAFETY INFORMATION • Avoid locations of high temperature or humidity. • The lamp is rated at IP65 for external use.
- Page 2 OPERATION • Allow at least 8hrs for the battery to fully charge initially. NOTE: the lamp does not light except in low ambient light levels. Solar panel. PIR Sensor. LED function display Operation mode button • Press the button one or more times to set the mode of operation. The corresponding indicator LED lights.
