Chapter 1
Overview
The 1stMainboard PAG-2130 is a MicroATX-sized Super 7 solution
offering high performance, the highest speeds for super 7 processors and
the very latest in quality onboard features. It supports the AMD® K6 ™ -III
400-450 MHz @ 100 MHz Front Side Bus and Pentium® MMX, AMD®
K6, AMD® K6-2, Cryix MII 300-366, IBM and IDT WinChip processors.
The PAG-2130 is based around the advanced architecture of the VIA
MVP4 and Super South chipset, giving advanced levels of performance
with high quality audio/visual capabilities.
The PAG-2130 comes with a
standard 1MB (manufacturing option: 2MB/512KB) of on-board cache.
With up to 2MB of SRAM cache on-board, the AMD K6-III 400-450MHZ
processors will significantly boot the PC's
performance.
The Super South chipset is a PC98 compliant PCI Super-I/O integrated
peripheral controller with integrated super-I/O, USB controller (with
support for four USB ports), keyboard controller, RTC, plug and play,
ACPI, enhanced power management, and temperature, voltage, and fan-
speed monitoring. With support for the new Ultra DMA66 protocol and its
high-speed interface, data transfer speeds and hard drive performance are
significantly improved.
The PAG-2130 has 3 DIMM for up to 768 MB SDRAM, and also offers
ECC memory support. It is equipped with, 4 PCI, and 1 ISA expansion slot.
The PAG-2130 is fully PC99 and Y2K compliant, and is ACPI ready,
ensuring improved energy efficiency. Other features include Wake-On-
LAN, IrDA,
Intel LDCM software (manufacturing option)
and CD Pro
with enhanced drivers. For the most up-to-date information about your
mainboard and the latest FAQs and BIOS updates, visit FIC Online at
http://ww.fic.com.tw.
1-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAG-2130 and is the answer not in the manual?

Questions and answers

Related Manuals for FIC PAG-2130

Summary of Contents for FIC PAG-2130

  • Page 1 The PAG-2130 has 3 DIMM for up to 768 MB SDRAM, and also offers ECC memory support. It is equipped with, 4 PCI, and 1 ISA expansion slot.

  • Page 2: Package Checklist

    PAG-2130 Mainboard Manual Package Checklist Please check that your package contains all the items listed below. If you discover that any item is damaged or missing, please contact your vendor. ü The PAG-2130 mainboard ü This user’s manual ü One IDE ribbon cable ü...
  • Page 3 Overview The PAG-2130 Mainboard...

  • Page 4: Main Features

    PAG-2130 Mainboard Manual Main Features The mainboard comes equipped with the most advanced new features that not only optimize the performance of the latest processors but also enhance the manageability, power management capabilities, and user-friendliness of your system. This section provides detailed information on these features, and how they are implemented on the mainboard.
  • Page 5 Overview...
  • Page 6 PAG-2130 Mainboard Manual Versatile Main Memory Support Accepts up to 768MB DRAM in three banks using DIMMs of 8, 16, 32, 64, 128, and 256MB with support SDRAM (66MHz and 100MHz) memory. Onboard IrDA Connector An IrDA connector for wireless infrared connections is available.

  • Page 7: Acpi Ready

    Overview Intel LANDesk Client Manager (LDCM) Software Support (optional) LDCM is a DMI-compliant application for local and network management of desktop client systems. The application reduces the number of help desk calls by supplying the user with self diagnostics such as a PC health meter and local alert of potential problems. ACPI Ready This mainboard fully implements the new ACPI (Advanced Configuration and Power Interface) 1.0 Hardware and BIOS requirement.
  • Page 8 PAG-2130 Mainboard Manual down again, thereby minimizing its power consumption. The Remote Ring-On function requires a power supply with a soft-off power controller. RTC Alarm The RTC alarm feature allows you to preset the computer to wake-up at a certain time to implement a number of useful functions, such as sending out a fax late a night automatically.
  • Page 9 Overview This Page Left Blank for Notes...

  • Page 10: Installation Procedures

    Chapter 2 Installation Procedures The mainboard has several user-adjustable jumpers/switches on the board that allow you to configure your system to suit your requirements. This chapter contains information on the various hardware settings on your mainboard. To set up your computer, you should follow these installation steps: Step 1 - Set system jumpers/switches Step 2 - Install memory modules Step 3 - Install the CPU...
  • Page 11 PAG-2130 Mainboard Manual This Chapter is intended to aid quick and easy installation. In the event that more detailed information is required, please consult the Installation Procedures Chapter. 2- 2...
  • Page 12 Installation Procedures...
  • Page 13 PAG-2130 Mainboard Manual 2- 4...
  • Page 14 Installation Procedures 2). CPU Fan Installation This connector is linked to the CPU fan. When the system is in suspend mode, the CPU fan will turn off; when it reverts back to full on mode, the fan will Without sufficient air circulation, the CPU may overheat and turn back on.
  • Page 15 PAG-2130 Mainboard Manual 5). Load BIOS Setup Default Load BIOS Defaults BIOS defaults contain the most appropriate values of the system parameters that allow minimum system performance. The OEM manufacturer may change the defaults through MODBIN before the binary image burns into the ROM.
  • Page 16 Installation Procedures Mainboard Layout...
  • Page 17 PAG-2130 Mainboard Manual Onboard Mark FUNCTION PAGE Clear CMOS Data Flash ROM Type Selection 2-10 DIMM1/2/3 DIMM Memory Module Support 2-11 CPU Internal Frequency Selection 2-14 SW1/2/3 CPU Ratio Selection 2-15 SW4/5/6/7/8 CPU to Bus Frequency Ratio Selection 2-16 PCI1/2/3/4...

  • Page 18: Set System Jumpers/Switches

    Installation Procedures 1). Set System Jumpers/Switches Clear CMOS: J5 The CMOS RAM is powered by the onboard button cell battery. To clear the RTC data: (1). Turn off your computer, (2). Enable this feature by placing the jumper cap to 2-3 pins on J5, or (3). Disable this feature by placing the jumper cap to 1-2 pins on J5, (4).
  • Page 19 PAG-2130 Mainboard Manual Flash ROM Type Selection: J7 This jumper allows you to configure the type of flash ROM chip. This jumper setting is correct by manufactory default. If you want to know the flash ROM type installed on this mainboard, remove the sticker from the chip to see its type.
  • Page 20 Installation Procedures 2). Install RAM Modules RAM Module Configuration PC100 modules may have a serial EEPROM containing a number of critical timing parameters and data regarding the chip and module vendor. This guarantees that the VIA MVP4 chipset will properly recognize the module by reading all of the important timing parameters specified in the EEPROM over the serial presence detect interface.
  • Page 21 PAG-2130 Mainboard Manual Install and Remove DIMMs This mainboard supports 100MHz SDRAM DIMMs; when the system frequency set to 100MHz, PC100-compliant SDRAM should be used. Complete the following procedures to install DIMMs: 1. Locate the DIMM slots on the mainboard.

  • Page 22: Install The Cpu

    Installation Procedures 3). Install the CPU The CPU module resides in the Zero Insertion Force (ZIF) socket on the motherboard. WARNING: 1. Always turn the system power off before installing or removing any device. 2. Always observe static electricity precautions. 3.
  • Page 23 PAG-2130 Mainboard Manual CPU Internal Frequency Selection: J6 These eight pins in four rows are used to decide the internal frequency of the CPU. Note: ON is short; OFF is open 2- 14...
  • Page 24 Installation Procedures CPU Ratio Selection: SW1/2/3 These three switches are used in combination to decide the ratio of the internal frequency of the CPU to the bus clock. 2-15...
  • Page 25 PAG-2130 Mainboard Manual CPU Core Voltage Selection: SW4/5/6/7/8 This section lists all possible CPU voltages that this board supports. There are five rows of CPU voltage (core voltage) switch setting in the diagram below. 2- 16...

  • Page 26: Install Expansion Cards

    Installation Procedures 4). Install Expansion Cards This section describes how to connect an expansion card to one of your system's expansion slots. Expansion cards are printed circuit boards that, when connected to the mainboard, increase the capabilities of your system. For example, expansion cards can provide video and sound capabilities.

  • Page 27: Connect Devices

    PAG-2130 Mainboard Manual 5). Connect Devices Connectors to Internal Devices Floppy Diskette Drive Connector: FLOPPY This connector provides the connection with your floppy disk drive. The red stripe of the ribbon cable must be the same side with the Pin 1.
  • Page 28 Installation Procedures ATX Power Connector: POWER This connector is connected to the ATX power supply. 2-19...
  • Page 29 PAG-2130 Mainboard Manual CPU Fan Connector: CPU_FAN This connector is linked to the CPU fan for cooling the processor temperature. When the system enters the suspend mode, the CPU fan will shut off. Please read the CPU fan installation guide before connection.
  • Page 30 Installation Procedures The table below was partly abstracted from the above-mentioned website for your convenience. Manufacture Contact Tel No. Manufacture Contact Tel No. A & P 408-260-9876 760-931-5700 Technology Power&Cooling Aavid 603-666-4100 Pentalpha Group 510-656-7100 886-2-8665-3248 ACT-RX 512-333-2375 Quality 626-960-1933 886-2-2218-8000 Computers 626-337-5025...
  • Page 31 PAG-2130 Mainboard Manual Wake-On-LAN Connector: WOL This 3-pin connector allows remote LAN servers to manage the system that installed this mainboard via a network adapter that also supports WOL. When you install a adapter with WOL connector, please read the network adapter card’s installation guide for details.
  • Page 32 Installation Procedures Connectors to System Case Front Panel Block Connector This block connector concludes the connectors for linking with IDE LED, power LED, remote power button, message LED, suspend button, reset button and speaker on the front panel of the system case. Please identify polarities of plug wires for the case speaker and LEDs.
  • Page 33 PAG-2130 Mainboard Manual System Case Fan Connector: CASE_FAN This 3-pin connector links to your cooling fan on the system case to lower the system temperature. 2- 24...
  • Page 34 Installation Procedures Connectors to External Devices PS/2 Keyboard and Mouse Connector: KB, MS These two 6-pin female connectors are used for your PS/2 keyboard and PS/2 mouse. Serial Port Connectors: COM1, COM2 The COM1 9-pin D-Sub male connector allows you to connect devices that use serial ports, such as a serial mouse or a modem.
  • Page 35 PAG-2130 Mainboard Manual Universal Serial Bus Connectors: USB0, USB1, USB2 These two connectors that integrated on the edge of the board are used for linking with USB peripheral devices. Also, this board provides an connector USB2 for linking with the USB socket on the front panel of some system cases.
  • Page 36 Installation Procedures Infrared Connector: IR This 5-pin connector is used to link with your IR device. CD-ROM Drive Audio-out Connector: CD_IN These 4-pin block connectors are linked to the AUDIO_OUT port of your CD-ROM drive by a cable which comes with it. Read the CD-ROM drive manual for detailed installation instructions.
  • Page 37 PAG-2130 Mainboard Manual Printer Connector: LPT This 25-pin D-Sub female connector is attached to your printer. Joystick/MIDI Connector: GAME This 15-pin female connector allows you to connect game joysticks or game pads for playing games. Connect MIDI devices for playing or editing audio.
  • Page 38 Installation Procedures Audio I/O Jacks: MIC IN, LINE IN, LINE OUT LINE OUT can be connected to headphones or preferably powered speakers. LINE IN allows tape players or other audio sources to be recorded by your computer or played through LINE OUT. MIC IN allows microphones to be connected for input voice.
  • Page 39 PAG-2130 Mainboard Manual This Page Left Blank for Notes 2- 30...

  • Page 40: Bios Setup

    Chapter 3 BIOS Setup The mainboard comes with an Award BIOS chip that contains the ROM Setup information of your system. This chip serves as an interface between the processor and the rest of the mainboard's components. This section explains the information contained in the Setup program and tells you how to modify the settings according to your system configuration.

  • Page 41: Standard Cmos Setup

    PAG-2130 Mainboard Manual Standard CMOS Setup The Standard CMOS Setup screen is displayed above. Each item may have one or more option settings. The system BIOS automatically detects memory size, thus no changes are necessary. Use the arrow keys to highlight the item and then use the PgUp or PgDn keys to select the value you want in each item.
  • Page 42 BIOS Setup MODE: Select Auto to detect the mode type automatically. If your hard disk supports the LBA mode, select LBA or Large. However, if your hard disk cylinder is more than 1024 and does not support the LBA function, set at Large. Select Normal if your hard disk supporting cylinders is below 1024.

  • Page 43: Bios Features Setup

    PAG-2130 Mainboard Manual BIOS Features Setup Anti-Virus Protection This feature starts the virus scan tool to detect if boot virus in boot sector of the first hard disk drive when booting up. The options are: Enabled (Default), Disabled. CPU Internal Cache When enabled, improves the system performance.
  • Page 44 BIOS Setup Boot From LAN First This feature makes the system bootable by the remote server via LAN. The options are: Disabled, Enabled (Default). Boot Sequence Allows the system BIOS to first try to boot the operating system from the selected disk drive. The options are: A, C, SCSI (Default); C, A, SCSI;...
  • Page 45 PAG-2130 Mainboard Manual Typematic Rate Setting The term typematic means that when a keyboard key is held down, the character is repeatedly entered until the key is released. The options are: Disabled (Default), Enabled. Typematic Rate (Chars/Sec) This feature is available only if the above item, Typematic Rate Setting, is set at Enabled.
  • Page 46 BIOS Setup Report No FDD For WIN 95 When the field under the Standard CMOS Setup Menu for Drive A and/or Drive B is set at None, users must set this field is set at Yes for it to function properly. Otherwise, set at No, even if field for Drive A and/or Drive B is set at None, system will still detect and recognize of a floppy drive(s).

  • Page 47: Chipset Features Setup

    PAG-2130 Mainboard Manual Chipset Features Setup Bank 0/1 DRAM Timing; Bank 2/3 DRAM Timing; Bank 4/5 DRAM Timing; This feature allows you to select the DRAM read/write speed. The options are: SDRAM 10ns (Default), SDRAM 8ns, Normal, Medium, Fast, Turbo.
  • Page 48 BIOS Setup When enabled, it makes the cache RAMs read and the data write to CPU faster. The options are: Enabled (Default), Disabled. Cache Timing The feature allows users to select the cache timing. The options are: Fast (Default); Fastest. Video BIOS Cacheable As with caching the System BIOS above, enabling the Video BIOS cache will cause access to the video BIOS addressed at C0000H to...
  • Page 49 PAG-2130 Mainboard Manual This option allows you to specify the frame biffer size of the AGP VGA card and/or PCI VGA card on the board. The options are: 8M (Default), 4M, NA. AGP Aperture Size It allows you to select the main memory frame size fo AGP use.
  • Page 50 BIOS Setup This feature is used to set the spread Spectrum to be center spread type or down spread type. The options are: Disabled, Enabled (Default). CPU Host Clock Select Default or select a timing combination for the CPU and the PCI bus.

  • Page 51: Power Management Setup

    PAG-2130 Mainboard Manual Power Management Setup Power Management This item allows you to adjust the power management features. Select Disable for disabling global power management features. Select User Defined for configuring your own power management features. MIN Saving initiates all predefined timers in their minimum values.
  • Page 52 BIOS Setup add-on VGA card. DPMS Supported allows the BIOS to blank off screen display by your add-on VGA card which supports DPMS (Display Power Management Signaling function). Blank Screen allows the BIOS to blank off screen display by turning off the red- green-blue signals.
  • Page 53 PAG-2130 Mainboard Manual The options 1 Min..15 Min and When Suspend will not work concurrently. When HDD is in the Power Saving Mode, any access to the HDD will wake the HDD up. The options are: Disable (Default), 1 Min..15 Min.
  • Page 54 BIOS Setup the PM timer even if no activity event is detected. The options are: OFF, ON (Default). PCI/master To set this feature at ON activates that Power Management feautre (PM) wake-up event for the DMA or bus master (of the LAN card or/and SCSI card).

  • Page 55: Pnp/Pci Configuration

    PAG-2130 Mainboard Manual The options for IRQ 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 15 are: Primary, Secondary, Disabled. The default value for IRQ 8, 15 is: Disabled. The default value for IRQ 3, 4, 5, 6, 7, 12, 13, 14 is: Primary.
  • Page 56 BIOS Setup Reset Configuration Data When enabled, allows the system to clear the last BIOS configuration data and reset with the default data. The options are: Enabled, Disabled (Default). CPU to PCI Write Buffer When enabled, allows data and address access to the internal buffer of the system controller;...
  • Page 57 PAG-2130 Mainboard Manual AGP Master 1 WS Read When enabled, the AGP bus master read access to the DRAMs will add one wait-state cycle. The options are: Disabled (Default); Enabled. Assign IRQ For USB If your USB device does not need an IRQ, select Disabled;...

  • Page 58: Load Bios Defaults

    BIOS Setup Load BIOS Defaults BIOS defaults contain the most appropriate values of the system parameters that allow minimum system performance. The OEM manufacturer may change the defaults through MODBIN before the binary image burns into the ROM. 3-19...

  • Page 59: Load Setup Defaults

    PAG-2130 Mainboard Manual Load Setup Defaults Selecting this field loads the factory defaults for BIOS and Chipset Features which the system automatically detects. 3- 20...

  • Page 60: Integrated Peripherals

    BIOS Setup Integrated Peripherals OnChip IDE Channel0 When enabled, allows you to use the onboard primary PCI IDE. If a hard disk controller card is used, set at Disabled. The options are: Enabled (Default), Disabled. OnChip IDE Channel1 When enabled, allows you to use the onboard secondary PCI IDE. If a hard disk controller card is used, set at Disabled.
  • Page 61 PAG-2130 Mainboard Manual IDE HDD Block Mode When enabled, the system executes read/write requests to hard disk in block mode. The options are: Disabled, Enabled (Default). Primary Master PIO Allows an automatic or a manual configuration of the PCI primary IDE hard disk (master) mode.
  • Page 62 BIOS Setup Primary Slave UDMA Allows you to select the first PCI IDE channel of the first slave hard disk mode or to detect it by the BIOS if the hard disk supports UDMA (Ultra DMA, faster than DMA). The options are: Disable, Auto (Default). Secondary Master UDMA Allows you to select the second PCI IDE channel of the secondary master hard disk mode or to detect it by the BIOS if the hard disk...
  • Page 63 PAG-2130 Mainboard Manual instead as an IR port. The options are: Standard (Default), ASK-IR, HPSIR. Parallel Port Mode Allows you to connect with an advanced printer. The options are: Normal (Default), EPP, ECP, ECP/ ECP. Onboard Parallel Port Allows you to select from a given set of parameters if the parallel port uses the onboard I/O controller.
  • Page 64 BIOS Setup The options are: DMA 1 (Default), DMA 2, DMA 3, DMA0. MPU-401 This feature allows you to select MPU-401, if the onboard Legacy audio chosen. The options are: Disabled (Default), Enabled. MPU-401 I/O Address This feature allows you to select the MPU-401 I/O address, if the onboard Legacy audio chosen.

  • Page 65: Supervisor/User Password

    PAG-2130 Mainboard Manual Supervisor/User Password To enable the Supervisor/User passwords, select the item from the Standard CMOS Setup. You will be prompted to create your own password. Type your password up to eight characters and press Enter. You will be asked to confirm the password.

  • Page 66: Ide Hdd Auto Detection

    BIOS Setup IDE HDD Auto Detection The IDE Hard Disk Drive Auto Detection feature automatically configures your new hard disk. Use it for a quick configuration of new hard drives. This feature allows you to set the parameters of up to four IDE HDDs. The option with (Y) are recommended by the system BIOS.

  • Page 67: Save And Exit Setup

    PAG-2130 Mainboard Manual Save and Exit Setup After you have made changes under Setup, press Esc to return to the main menu. Move cursor to Save and Exit Setup or press F10 and then press Y to change the CMOS Setup. If you did not change anything, press Esc again or move cursor to Exit Without Saving and press Y to retain the Setup settings.

  • Page 68: Exit Without Saving

    BIOS Setup Exit without Saving If you select this feature, the following message will appear at the center of the screen to allow you to exit the setup utility without saving CMOS modifications: Quit Without Saving (Y/N)? 3-29...
  • Page 69 PAG-2130 Mainboard Manual This Page Left Blank for Notes 3- 30...
  • Page 70 PAG-2130 MAINBOARD MANUAL DOC No. : M98A03 Rev. : A2 Date : 12, 1999 Part No. : 25-10917-22...
