Auto Crane 3203 P Owner's Manual page 50

View thousands of Crane Specifications on FreeCraneSpecs.com
View thousands of Crane Specifications on FreeCraneSpecs.com
ITEM QTY
1 1
2 1
3 1
4 1
5 1
6 1
7 2
8 1
9 1
10 1
11 1
12 1
13 1
14 1
15 -
16 1
17 1
18 2
19 1
20 1
21 1
22 1
23 2
24 3
25 2
26 1
27 1
28 10
29 12
30 4
31 1
32 4
33 4
34 1
35 1
36 3
37 4
38 2
HOIST ACTUATOR ASSEMBLY
P/N 320324
P/N DESCRIPTION
360637 FLAT SPRING
360331 CAM PLATE
300041 GEAR HOUSING COVER
300042 SPUR GEAR HOUSING COVER
360450 BRAKE COVER
300043 IDLER GEAR
300044 SPUR GEAR
300045 WORM R.H. GEAR
300046 PINION GEAR
360336 BRAKE HOUSING
300047 SPUR GEAR HOUSING
300048 GEAR HOUSING
360339 BRAKE HUB
300049 KEY 3/16 SQ x 1/2 LG
- -
300050 KEY 3/16 SQ x 1 9/16 LG
341561 KEY 1/4 SQ x 2 3/4 LG
300052 KEY RD 5/16 x 5/16 x 15/16 LG
360342 RETAINER PLATE
300053 SPUR GEAR SHAFT
320323 OUTPUT SHAFT
320312 RIGHT HAND WORM GEAR
360345 BALL
300056 NEEDLE BEARING
300057 BALL BEARING
300058 BUSHING
300059 BUSHING
320313 CAPSCREW 1/4-20 NC x 3/4 LG NYLOCK
005500 CAPSCREW 1/4-20 NC x 3/4 LG
005604 CAPSCREW 1/4-20 NC x 1 LG
320311 CAPSCREW 3/8 x 1 1/2 LG ALL THREAD
320310 CAPSCREW 1/4-20 NC x 1 LG
300060 SOCKET HEAD SCREW 1/4-20 NC x 3/4 LG LOC-WEL
300061 SETSCREW 1/4-20 NC x 5/16 LG LOC-WEL
360353 HEX JAM NUT 3/8-16 NC
071012 HEX NUT 3/8-24 NF
360354 SPLIT LOCK WASHER 1/4 MED SECT
360455 FLAT WASHER 1/4 ALUM
3-3.1.0 AW320324 2/99
