- Page 1 Maxi Sky 2 Transportable Installation Manual ...with people in mind 001-31430-EN rev.1 • 05/2017...
- Page 2 Design Policy and Copyright ® and ™ are trademarks belonging to the ArjoHuntleigh group of companies. © ArjoHuntleigh 2017. As our policy is one of continuous improvement, we reserve the right to modify designs without prior notice. The content of this publication may not be copied either whole or in part without the...
-
Page 3: Table Of Contents
How To Install the Receiving Module ....................... 7 Install/Remove Maxi Sky 2 Transportable .................8 Prepare to install the Maxi Sky 2 Transportable into the Receiving Module ..........8 How to install the Maxi Sky 2 Transportable inside the Receiving Module ..........9 Finish installation of the Maxi Sky 2 Transportable into the Receiving Module ........11... - Page 4 Intentionally Left Blank...
-
Page 5: Safety Instructions
When in doubt refer to local authorities for health and safety requirements. When the Maxi Sky 2 Transportable is being mounted or unmounted from the receiving module, always make sure not to drop the Maxi Sky 2 Transportable to ensure no injuries are caused to bystanders or to yourself. -
Page 6: Intended Use
Intended Use Maxi Sky 2 Transportable receiving module is WARNING:To avoid bodily injuries, only use a receiving module which enables relocation of the Maxi Sky 2 receiving module with Maxi a Maxi Sky 2 ceiling lift from a Kwiktrak to... -
Page 7: Product Description
CAUTION: Make sure you are using the Receiving Module corresponding to the Kwiktrak rails system and to the Maxi Sky 2 Transportable available in your institution. The ECS and the C-Stat sytems involve two different charging systems that are not interchangeable and can only be used within their own systems. - Page 8 Intentionally Left Blank...
-
Page 9: Parts Description
Parts Description Before proceeding with the installation, get familiar with the various parts of the specific receiving module compatible with the track system and the Maxi Sky 2 unit you have. List of Parts for the Receiving Modules Number ECS cable ECS contact box receiving module door slider... -
Page 10: Install Receiving Modules
Install Receiving Modules Required Tools • 6 mm allen key In addition, a sturdy stepladder will be required to reach the track and secure the module inside the Kwiktrak. The receiving modules must be installed by an authorized contractor or installer and in accordance to local regulations. -
Page 11: How To Install The Receiving Module
REMINDER: If an ECS receiving module is being installed, special care must be taken during the procedure to ensure the ECS Maxi Sky 2 Transportable will be able to charge properly after it is installed into the ECS receiving module. -
Page 12: Install/Remove Maxi Sky 2 Transportable
This step should be taken when the Maxi Sky 2 Transportable has to be transported from one room to another. Locate a stepladder and bring it to the room where the Maxi Sky 2 Transportable will be taken out of the receiving module: 1) Remove the spreader bar connected to the Maxi Sky 2 Transportable strap;... -
Page 13: How To Install The Maxi Sky 2 Transportable Inside The Receiving Module
How to install the Maxi Sky 2 Transportable inside the Receiving Module 1) Open the door of the receiving module, which locks the module in place and enables the insertion of the Maxi Sky 2 Transportable's wheels inside; (Fig. 11) - Page 14 Maxi Sky 2 Transportable is locked inside the receiving module; (Fig. 17) Fig. 17 5) Turn the Maxi Sky 2 Transportable ON by gently pushing in the emergency stop and look for the green light LED indicator to light up;...
-
Page 15: Finish Installation Of The Maxi Sky 2 Transportable Into The Receiving Module
Finish installation of the Maxi Sky 2 Transportable into the Receiving Module 7) Bring the strap down and remove the remote from the strap; (Fig. 23) Fig. 23 8) Connect the spreader bar to the Maxi Sky 2 Transportable strap; (Fig. 24) Fig. -
Page 16: Prepare To Remove The Maxi Sky 2 Transportable From The Receiving Module
This step should be taken when the Maxi Sky 2 Transportable has to be transported from one room to another. Locate a stepladder and bring it to the room where the Maxi Sky 2 Transportable will be taken out of the receiving module: 1) Remove the spreader bar connected to the Maxi Sky 2 Transportable strap;... -
Page 17: How To Remove The Maxi Sky2 Transportable From The Receiving Module
Fig. 32 Fig. 34 steps on page 8. CAUTION: After the Maxi Sky 2 Transportable was removed, close the door of the receiving module. The door must be closed to ensure its functionality is maintained. Install/Remove Maxi Sky 2 Transportable... -
Page 18: Care And Maintenance
Make sure to recharge the batteries as soon as possible. Let the batteries recharge for a complete charging cycle. NOTE: If the product does not work as intended, immediately contact your local ArjoHuntleigh agent for support. -
Page 19: Inspection
The receiving modules, for both the ECS system and the C-Stat system, must be dusted and cleaned every month. Points For Inspection / after every Maxi Sky 2 Transportable installation 1. Make sure the door of the receiving module can stay closed. -
Page 20: Cleaning
Preventive and Maintenance Schedule The receiving module must be part of an inspection by a qualified ArjoHuntleigh technician on an annual basis to ensure proper functioning of its components, as well as the safety of the patients and caregivers who use the system. Please contact your local representative to make... -
Page 21: Troubleshooting
Troubleshooting Should there be a malfunction with the Maxi Sky 2 Transportable following the installation of the receiving module, please verify the following points: List of Potential Problems Solutions/Actions The Rivet does not come • Call your local ArjoHuntleigh representative. -
Page 22: End-Of-Life Disassembly Instructions
End-of-Life Disassembly Instructions Important • This section describes End-of-Life • Special waste: This product disassembly of the receiving Modules. contains electrical components. Discard disposable, replaced and • The Receiving Modules are used in left-over parts in accordance with hospitals, care centers and/or Licensed appropriate industrial and Care and retirement facilities. -
Page 23: Contruction Material
Contruction material The construction material used in the Receiving Modules in % of the total weight. ECS Receiving Module Metal - total 88 % • Aluminum 66 % • Steel, zinc 22 % Electronics - total 2 % • Cables & Copper Polymeric material - total 10 % •... -
Page 24: Disassembly Instructions
Disassembly Instructions ECS Receiving Module Polyamide (not Polycarbonate reinforced) Aluminum Cables Steel overmoulded with acetal Acetal Aluminum Polyamide (reinforced with glass fiber) Polyamide Aluminum (reinforced with glass fiber) Steel, zinc Polyamide (not reinforced) Steel, zinc C-Stat Receiving Module Polyamide (not Aluminum Polyamide reinforced) -
Page 25: Curtain Gap Receiving Module
Curtain Gap Receiving Module Polyamide Aluminum (reinforced Steel, zinc Acetal with glass fiber) Aluminum Steel overmoulded with acetal Polyamide (reinforced Steel, zinc with glass Aluminum fiber) Polyamide (not reinforced) Polyamide (reinforced with glass fiber) - Page 26 Intentionally Left Blank...
