Summary of Contents for Starrett FORM 966

  • Page 2 LEA ATENTAMENTE ESTE MANUAL LIRE CE MANUEL AVANT D'UTILISER L'INSTRUMENT LEIA ATENTAMENTE ESTE MANUAL ANTES DE UTILIZAR O INSTRUMENTO 使用仪器前请阅读本操作手册 DIESES HANDBUCH VOR DER VERWENDUNG DES MESSGERÄTS LESEN LEGGERE ATTENTAMENTE QUESTO MANUALE PRIMA DI UTILIZZARE QUESTO STRUMENTO FORM 966 01/18...
  • Page 3 2900 ELECTRONIC INDICATOR USER MANUAL...

  • Page 4: Table Of Contents

    Setting the Preset Function Setting MIN/MAX Limits (Go/No Go) Displaying MIN/MAX/TIR Values** Lock Mode* Data Output Connection Battery Installation Appendix A: Technical Specifications Appendix B: Serial Output Connector *Available with Standard and Advanced Features **Available only with Advanced Features FORM 966...
  • Page 5 2900 ELECTRONIC INDICATOR THIS IS A STARRETT USER GUIDE FOR THE 2900 ELECTRONIC INDICATOR. ALL SPECIFICATIONS IN THIS DOCUMENT ARE CORRECT AT TIME OF PRODUCTION AND ARE SUBJECT TO CHANGE. PLEASE CONTACT STARRETT FOR FURTHER INFORMATION. FORM 966...

  • Page 6: Guidelines For Indicator Care

    Put the spindle carefully on to its surface. The measured value will be shown on the LCD. 9. Press and hold the ON/OFF button to turn the indicator off. If left unattended, it will turn off automatically in 30 minutes. FORM 966...

  • Page 7: Indicator Components, Dimensions And Layout

    ENGLISH INDICATOR COMPONENTS, DIMENSIONS AND LAYOUT 1-21/32" (42.2mm) Stem Cap 1/4" (6.5mm) 2-5/64" (53mm) 3/8" Stem (9.5mm) Data Output Cover Spindle Data Cable Bellows Spindle Back Lug Contact Point 1/4" (6.5mm) Battery Drawer FORM 966...

  • Page 8: Button Functions

    Press HOLD momentarily to capture a reading. The captured reading 11 HOLD will flash on and off. To disable, press the HOLD button again. Displays the minimum or maximum values captured during 12 MIN/MAX/TIR operation. The TIR function displays the difference between the captured readings. FORM 966...

  • Page 9: 2900 Indicator Models, Feature Level And Resolution

    SHIFT / SET Press Then to enter Resolution Mode BUTTON Button Press to cycle through the available resolutions Button SHIFT / SET Press to pick the resolution and exit resolution mode BUTTON *Available with Standard and Advanced Features FORM 966...

  • Page 10: Setting The Preset Function

    1. Select the units to be displayed. 2. Press the SHIFT/SET button. The SET icon will appear in the lower left corner (right). 3. Press the LIMITS button. The MIN LIMIT icon will appear in the upper middle of the display. FORM 966...
  • Page 11 SHIFT / SET Then press BUTTON The LIMIT icon will stop flashing. The Indicator is now set up with a maximum and LIMITS Press Button minimum limit range LIMITS Press To exit the LIMIT mode. Button **Available with Advanced Features FORM 966...

  • Page 12: Displaying Min/Max/Tir Values

    SHIFT/SET then the LOCK buttons. The lock icon will turn off and stay off. SHIFT / SET LOCK Press Then to activate the Lock function BUTTON Button SHIFT / SET LOCK Press Then to deactivate the Lock function BUTTON Button *Available with Standard and Advanced Features FORM 966...

  • Page 13: Data Output Connection

    Remove the battery drawer and discard the old batteries. Place two new CR2032 batteries into the tray with the positive (+) side facing up. Slide the tray carefully into the indicator and secure with the two screws. To order CR2032 batteries, specify: PT99492. EDP 65650 FORM 966...

  • Page 14: Appendix A: Technical Specifications

    Character strings to indicate units "IN" or "mm" Carriage return Line feed COMMUNICATION PROTOCOL Baud Rate 4,800 Data Bits Parity None Stop Bits Flow Control None Receive High to Low Momentary Data Request and Response Timing Response Time Delay 120 ms Transmit Time 45 ms FORM 966...
  • Page 15 Low Level Vss +0.25 @ -1.5mA Load High Level Vdd –0.25 @ 1.25 mA Load Note: Vss = 0 Volts, Vdd = 2.7 to 3.6 Volts ENVIRONMENTAL CONSIDERATION Temperature 10-30 °C, Humidity 30-85%RH (no condensation) Atmosphere Non-corrosive, Non-flammable FORM 966...
