Page 1
Owner’s Record The model number and serial number are on the back of the unit. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this unit. Model number: Serial number :...
Introduction SAFETY PRECAUTIONS CAUTION: VISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM. AVIS WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. IMPORTANT SAFETY INSTRUCTIONS 1.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. WARNING: Changes or modifi cations to this unit not expressly approved by Toshiba, or parties authorized by Toshiba, could void the user’s authority to operate the equipment.
Introduction Supplied Accessories BONUSVIEW Remote Control with Composite Audio / Video Batteries (AAA x 2) Cables OWNER’S MANUAL Owner’s Manual Quick Start Guide (EN) (EN/ES) Symbols Used in this Manual To specify for which media type each function is, we put the following symbols at the beginning of each item to operate.
Table of Contents Introduction SAFETY PRECAUTIONS ...2 IMPORTANT SAFETY INSTRUCTIONS ... 2 PRECAUTIONS ... 3 Supplied Accessories ... 4 Symbols Used in this Manual ... 4 Trademark Information ... 4 Table of Contents ... 5 Features ... 6 Identifi cation of Controls ... 7 Front panel ...
Introduction Features Blu-ray Disc You can enjoy Blu-ray Disc which is capable of storing fi ve times more data than a conventional DVD. BD-Java With some BDs which support Java applications, you can enjoy the interactive functions such as games or interactive menus. BD-Live BD-Live (BD-ROM version 2 Profi...
Identifi cation of Controls Front panel (*) Notes: 1. These indicators are located in the sensor fi eld. 2. When this unit is off, these indicators are dimmed. If a fi n- ger is brought close to the sensor fi eld, the indicators will be invoked and light up.
Introduction Using the Remote control Remote control BONUSVIEW No. Item Description Press to adjust aspect ratio in full ASPECT stop mode. OPEN/CLOSE Press to open or close the disc tray. Press to display the settings in SETTING home menu. Press to display the Connected in HOME MENU home menu.
• In playback mode, press GOTO, then press the number buttons to enter a title, chapter, track, Number buttons time or fi le number. • In menu mode, press to enter the parental code password. Press to display the search GOTO menu.
Introduction Operating with the remote control Point the remote control at the remote sensor and press the buttons. Distance: About 5 m from the front of the remote sensor. Angle: About 30° in each direction of the front of the remote sensor. Front Panel Display 1080ip 720p...
Connecting to a TV Connect the Blu-ray player to your TV. 1. Choose the appropriate connection, then proceed to the corresponding instruction (A, B or C) on the next page. Best (Supports up to 1080i/1080p, 1080p/24F resolution.) HDMI cable Video Audio No analog audio connection required.
Connections 2. Connect the cables by following the illustrations below. Connecting to a TV using an HDMI cable (Best) COMPONENT VIDEO OUT AC IN BITSTREAM / PCM VIDEO HDMI OUT OPTICAL AUDIO OUT HDMI OUT Notes: • Do not tilt the connector when inserting it into the HDMI jack, and make sure the shapes of the jack and the connector are matched.
Connecting to an Audio System • When you change the connections, all devices should be turned off. • Refer to the manual accompanying external devices for more information. Via 2-Channel Analog Audio Output COMPONENT VIDEO OUT AC IN BITSTREAM / PCM VIDEO HDMI OUT OPTICAL...
Connections Network Connection Your Blu-ray disc player can be connected to your home network: • By connecting an Ethernet cable to the ETHERNET jack on the rear of your player and to a wired hub or router. Using a wired network provides the best performance, because the attached devices connect directly to the network and are not subject to radio frequency interference.
Connecting the Speakers (For 7.1 Audio Channel) You can connect the speakers as shown in the following diagram to obtain the 7.1 audio channels effects. Using the audio cables, connect the MULTI CHANNEL AUDIO OUTPUT (SBL, SBR, C, SW, SL, SR, FL & FR) terminals on the rear of the Blu-ray disc player to 7.1 Channel ANALOG AUDIO IN terminals of your Amplifi...
Connections Positioning the Speakers (For 7.1 Audio Channel) How you set up your speakers can affect the bass and the sound fi eld. Note the following points: • Place speakers on fl at secure bases. • Placing speakers too close to fl oors, walls, and corners can result in excessive bass. Cover walls and windows with thick curtains.
Playback Information on Playback Before you start playing back a disc, read the following information. Playable Discs and Files This unit is compatible to play back the following discs / fi les. To play back a disc / fi le, make sure that it meets the requirements for region codes and color systems as described below.
Playback Color Systems BD-video and DVD-video are recorded in different color systems throughout the world. The most common color system is NTSC (which is used primarily in the United States and Canada). Region Codes This unit has been designed to play back BD-video with region “A”...
Playing a Disc This section shows you the basics on how to play a disc. Basic playback Preparations • When you want to view a disc, turn on the TV and select the video input connected to the Blu-ray disc player. Press the ON/STANDBY button.
Playback Variable Speed Playback You can play discs at various speeds, and resume playback from the location where you stopped playback. Playing in fast reverse / forward directions Press during playback. : Fast forward playback : Fast reverse playback Each time you press this button, the fast-forward or fast-reverse speed changes in the following sequence: Fast x 2...
Locating a specifi c chapter or track Press repeatedly to access the chapter or track number you want. Playback starts from the selected chapter or track. To locate succeeding chapters or tracks. Playback starts from the beginning of the current chapter or track. When you press twice in quick successions, playback starts from the beginning of the preceding chapter or track.
Playback Repeating a Title, Chapter, Track or Specifi c Segment Repeating a title, chapter or track Press REPEAT repeatedly to select the desired repeat mode during playback. e.g. Repeat Off Repeat Title Repeat Chapter Repeat Off Repeat All Repeat Track Repeat Off Repeat All Repeat File...
PIP (BONUSVIEW) Setting Some Blu-ray discs have the PIP function which enables you to display the secondary video in the primary video. You can call up the secondary video by pressing BONUS VIEW whenever the scene contains the secondary video. See the documentation that came with the disc for playback instructions.
Playback Subtitle Selection During playback, press SUBTITLE. Subtitle 01/07 ENG PIP Subtitle Displaying On-screen Information You can check information about the current disc by pressing On-Screen display Disc format BD-ROM CD-DA In the example “01/07 ENG”, “01” indicates the currently selected subtitle. “07”...
Playing AVCHD/MP3/WMA/JPEG Files You can play AVCHD, MP3, WMA or JPEG fi les that have been recorded on a disc on the Blu-ray disc player. Playing fi les on a data disc When you insert a data disc containing picture, music, or video fi les into your player, icons are added to the menu to indicate that video, music, or picture fi...
Playback Pictures Optical Disc 30 item(s) Main Menu Settings Thumbnail Media Menu Start Slide Show Browse Music Now Playing File: 13/30 : displays source (Optical Disc/USB/SD) device name. : defi nes the total number of fi les that a device contains. : shows the currently playing fi...
Using a USB Device You can play MP3, WMA or JPEG fi les that have been stored on USB devices on the Blu-ray disc player. Operating a USB device Inserting a USB device into the USB slot on the back of Blu-ray disc player until it clicks.
Function setup Customizing the Function Settings You can change the default settings to customize performance to your preference. General Operations 1. Press to select Settings in home menu while in full stop mode, the Settings menu appears. 2. Press button, then use button to select the setting options.
Customizing the Function Settings BD-Live Internet Access: • Limit Access — Allows Internet access with valid “BD- Live” network access approval. • Always Allow Access — Always allows BD-Live Internet access. • Prohibit Access — Never allows BD-Live Internet access. In order to set the player up for BD-Live Internet Access, perform the following steps: 1.
Page 30
Function setup Customizing the Function Settings TV Type V Type If your TV is a high-defi nition TV(HDTV) connected to the HDMI jack on your player and you want your player to set the output resolution based on informa- tion exchanged between the TV and your player over the HDMI cable.
Customizing the Function Settings Audio Setting The settings in the Audio menu will confi gure the BD player’s digital audio outputs (HDMI or Optical). 1. In the main menu of Settings, press button, then use button to select Audio, then press OK button. Audio PCM Downsampling 48 kHz...
Function setup Customizing the Function Settings Selecting the “Auto” option turns on the Dynamic Range Control for all BD movie soundtracks except Dolby TruHD. If you have selected a TruHD track on the BD disc, the “auto” selection tells the BD player to only turn on dynamic range control if information embedded in the TruHD sound track tells it to do so.
Customizing the Function Settings Language Setting 1. In the main menu of Settings, press Language, and then press OK. Language English Menu English Audio Auto Subtitle None 2. Press to select OSD, Menu, Audio or Subtitle, and then press OK. 3.
Function setup Customizing the Function Settings Setting the parental control level 1. In the main menu of Settings, press , then press to select Parental, and then press OK. 2. Press to select Parental Level, then press OK. 3. Press to select the rating level you want to block, then press OK.
Customizing the Function Settings Update Via Network: This option displays the required storage space if the BD player is connected to internet for upgrade. For detailed upgrade operation, please refer to “Upgrading Your Player’s Firmware” on this page. Restore factory defaults: Choose one of the following 7 options, then press OK to pop up a dialog box, choose Ok in the box, and then press OK to confi...
Function setup Customizing the Function Settings Network Connection Setting 1. Press to select Network in stop mode, then press button, If no Ethernet cable is connected to the ETHERNET jack on the back of your player, a screen similar to the following appears: Wireless Network List...
Page 37
Customizing the Function Settings The symbols that might appear next to each listed wireless network in the network list are as follows: Category Icon Defi nition Connected When the BD player is turned on, it will connect to the wireless network displaying this symbol.
Page 38
Function setup Customizing the Function Settings Done 2 3 4 5 6 7 8 9 0 q w e r t y u i o p a s d f g h j k l ; b n m , . / x c v ` - = Space...
2. Creating Netfl ix account If you are not a Netfl ix Member: Select “no”. Read the instructions displayed on the TV screen, and visit http://www.netfl ix.com/toshiba from your PC. Sign up to create your account, then select “I’m now a member”.
Function setup Using the Connected Applications Watching Movies with BLOCKBUSTER This Blu-ray Disc Player enables you to use the following services provided by Blockbuster. 1. In Home Menu, press to select Connected. 2. Press , then press to highlight Blockbuster, and then press OK to enter Blockbuster main menu. •...
Using the Connected Applications Listening to Music with PANDORA Using an existing Pandora account 1. In Home Menu, press to select Connected. 2. Press , then press to highlight Pandora, and then press OK to confi rm. 3. Select “I have a Pandora account” from the option list. 4.
Others Troubleshooting & Maintenance Troubleshooting If the unit does not perform properly when operated as instructed in this manual, check the unit, consulting the following checklist. Problem No power - Check if the AC cord is properly connected. - Unplug the AC cord once, and wait for 5-10 seconds and then plug it in again. No sound or picture - Check if the connected TV is turned on.
Others Troubleshooting & Maintenance Problem The password for rating level has - If you forget your password, reset your player to the factory defaults and your been forgotten Cannot connect to the network - Check if the LAN cable connection is properly made. - Turn on the modem or broadband router.
Others Glossary Analog Audio An electrical signal that directly represents sound. Compare this to digital audio which can be an electrical signal, but is an indirect representation of sound. Aspect Ratio The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the TV screen is almost square);...
Page 45
Others Glossary LAN (Local Area Network) A group of computer networks covering a small area like a company, school or home. Local Storage A storage area of sub contents for playing virtual packages on BD-video. MP3 (MPEG audio layer 3) MP3 is a method of compressing fi...
Others Specifi cations Signal system Power requirements Power consumption Dimensions (width x height x depth) Weight Operating temperature Operating humidity Video output RCA jack 1 Vp-p (75Ω ) Component video output RCA jack x 3 Y: 1 Vp-p (75Ω ) Video: 480i, 480p, 720p, 1080i HDMI output HDMI jack x 1...
Limited United States Warranty Digital Audio Video (“DAV”) Product - Exchange Warranty Toshiba America Consumer Products, L.L.C. (“TACP”) makes the following limited warranties to original consumers in the United States. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS DAV PRODUCT AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.
Page 48
VUDU™, Netfl ix®, BLOCKBUSTER® on Demand, Pandora® and other internet services are available only in the United States, and are not provided by Toshiba, may change or be discontinued at any time and may be subject to internet service provider restrictions.
Page 49
Article 7 Termination of License In the event that you fail to comply with any of the terms and conditions contained herein, Toshiba shall have the right to immediately terminate this Agreement without any notifi cation to you. Upon termination of this Agreement, you shall cease all...
Page 50
However, some of the software components distributed under an EULA are made available for use by the user on the assumption that they are not copyrighted or warranted by TOSHIBA or any third party. These software components are licensed to the user free of charge and therefore not covered by any warranty within the scope of the applicable laws.
Page 51
Others jpeg The terms and conditions which apply to this software are provided in Appendix B. expat The terms and conditions which apply to this software are provided in Appendix I. The terms and conditions which apply to this software are provided in Appendix C. The terms and conditions which apply to this software are provided in Appendix D.
Page 53
Others Luxi Font Copyright Luxi fonts copyright (c) 2001 by Bigelow & Holmes Inc. Luxi font instruction code copyright (c) 2001 by URW++ GmbH. All Rights Reserved. Luxi is a registered trademark of Bigelow & Holmes Inc. Permission is hereby granted, free of charge, to any person obtaining a copy of these Fonts and associated documentation fi...
Page 54
Others Appendix C - MNG License /* ************************************************************************************************************************************************** COPYRIGHT NOTICE: Copyright (c) 2000 Gerard Juyn (gerard@libmng.com) [You may insert additional notices after this sentence if you modify this source] For the purposes of this copyright and license, “Contributing Authors” is defi ned as the following set of individuals: Gerard Juyn The MNG Library is supplied “AS IS”.
Page 55
Others Appendix G – Freetype License The FreeType Project LICENSE ---------------------------- 2006-Jan-27 Copyright 1996-2002, 2006 by David Turner, Robert Wilhelm, and Werner Lemberg Introduction ============ The FreeType Project is distributed in several archive packages; some of them may contain, in addition to the FreeType font engine, various tools and contributions which rely on, or relate to, the FreeType Project.
Page 56
Others These conditions apply to any software derived from or based on the FreeType Project, not just the unmodifi ed fi les. If you use our work, you must acknowledge us. However, no fee need be paid to us. 3. Advertising -------------- Neither the FreeType authors and contributors nor you shall use the name of the other for commercial, advertising, or promotional purposes without specifi...
Page 57
Others Original SSLeay License ----------------------- /* Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and non-commercial use as long as the following conditions are aheared to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code;...
Page 58
Others Appendix K – GNU GPL 2.0 GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The licenses for most software are designed to take away your freedom to share and change it.
Page 59
Others c) Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in object code or executable form with such an offer, in accord with Subsection b above.) The source code for a work means the preferred form of the work for making modifi...
Page 60
Others Appendix L – GNU LGPL 2.1 GNU LESSER GENERAL PUBLIC LICENSE Version 2.1, February 1999 Copyright (C) 1991, 1999 Free Software Foundation, Inc. 59 Temple Place, Suite 330, Boston, MA 02111-1307 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. [This is the fi...
Page 61
Others Activities other than copying, distribution and modifi cation are not covered by this License; they are outside its scope. The act of running a program using the Library is not restricted, and output from such a program is covered only if its contents constitute a work based on the Library (independent of the use of the Library in a tool for writing it).
Page 62
Others c) Accompany the work with a written offer, valid for at least three years, to give the same user the materials specifi ed in Subsection 6a, above, for a charge no more than the cost of performing this distribution. d) If distribution of the work is made by offering access to copy from a designated place, offer equivalent access to copy the above specifi...
Page 63
Others How to Apply These Terms to Your New Libraries If you develop a new library, and you want it to be of the greatest possible use to the public, we recommend making it free software that everyone can redistribute and change. You can do so by permitting redistribution under these terms (or, alternatively, under the terms of the ordinary General Public License).
Page 64
Others THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.
