Tenma 21-10130 Quick Start Manual

Soldering & Rework Station
Apply
Industrial production
Research department
Maintenance industry
Students
Electronic assembly
All enterprises and institutions
An intelligent, lead-free, and space-saving rework station which combines a rework station and soldering station. It is suitable
for advanced hobbyists, repair, rework, and educational use. It is user friendly and a welcome addition to every work bench
Specifications
Model
Total power
Range for temperature controlling
Temperature unit
Temperature controlling stability
Temperature controlling accuracy
Calibration range
Setting storage (3 groups)
Range of air volume
Dormancy and standby
Cold air
Malfunction alert
Shutdown
www.element14.com
www.farnell.com
www.newark.com
www.cpc.co.uk
www.mcmelectronics.com
21-10130
About 900 W (maximum)
Hot air rework station
Soldering station
°C/°F
Static
Static
Celsius
Fahrenheit
Rework station
Soldering station
Rework station
Rework station
Rework station
Heating elements
Sensor
Shutdown in the normal condition Cold air delay shutdown, power off
Page <1>
Features:
• Advanced integrated computer provides outstanding
thermo-control and thermo-stability for precise
temperature control
• Dual LCD displays the working and parameter
temperatures
• Quick-to-temp power up
•  H ighflowdiaphragmpumpissuitableforavarietyof
nozzles to desolder SMD components
• Automatic shut-off and sleep mode for safety and
energy savings
• Convenient buttons on the hand piece allow instant
adjustment of temperature and air volume
• Memory stores up to three air and temperature presets
Intelligent lead-free rework station
Heating : 800 (maximum) pump (diaphragh) : 40 W
100°C to 500°C
200°C to 480°C
Convertible
2°C
10°C
-50°C to 50°C
-58°F to 122°F
1.2°C, 40 2.3°C 60 3.4°C 80
1.2°C 2.3°C 3.4°C
020 - 100 level
Stopping heating, air-blowing delay and then be in
the condition of dormancy
Air-blowing made by the machine
Displaying H-E
Displaying S-E
TM
TM
03/12/12 V1.0
