This appliance can be used by children aged form 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
The specific instructions related to the safe operation of this appliance (as given in
7.12 of this standard) shall be collated together in the front section of the user
instructions.
The height of the characters, measured on the capital letters, shall be at least 3
mm.
These instructions shall also available in an alternative format, e.g. on a website.
A fire may result if the appliance is not used with care, therefore:
→
be careful when using the appliance in places where there are combustible
materials ;
→
do not apply to the same place for a long time;
→
do not use in presence of an explosive atmosphere;
→
be aware that heat may be conducted to combustible materials that are out
of sight;
→
place the appliance on its stand after use and allow it to cool down before
storage;
→
do not leave the appliance unattended when it is switched on.
Rohs
Correct Disposal of this product
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent pos-
sible harm to the environment or human health from uncon-
trolled waste disposal, recycle it responsibly to promote the sus-
tainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the re-
tailer where the product was purchased. They can take this
product for environmental safe recycling.
www.Tenma.com
Soldering Station
Instruction Manual
Thank you for purchasing the 21-19650 Soldering Station.
Please read the manual before using the unit.
Keep manual in accessible place for future reference.
21
-
19650
21
-
19650
Advertisement
Table of Contents
Related Manuals for Tenma 21-19650
Summary of Contents for Tenma 21-19650
- Page 1 → do not leave the appliance unattended when it is switched on. Rohs Thank you for purchasing the 21-19650 Soldering Station. Correct Disposal of this product Please read the manual before using the unit. This marking indicates that this product should not be disposed Keep manual in accessible place for future reference.
-
Page 2: Basic Troubleshooting Guide
BASIC TROUBLESHOOTING GUIDE PROBLEM 1: THE UNIT HAS NO POWER 1. Check if the unit is switched ON. 2. Check the fuse. Replace with the same type if fuse is blown. This manual is designed to familiarize and instruct the techni- 3. -
Page 3: Table Of Contents
CARE AND MAINTENANCE TABLE OF CONTENTS 1. Tip Temperature : High temperature shortens tip life and may cause thermal shock to components. Always use the lowest possi- ble temperature when soldering. Standard temperature settings are Product Description …………………………………… 350 to 400 degrees Celsius. Package Inclusion ……………………………………... -
Page 4: Product Description
OPERATING GUIDELINES PRODUCT DESCRIPTION With the auto-calibration adaptor attached, tip calibration can be The TENMA 21-19650 is a high performance induction heating done via the following method: soldering iron. It is equipped with a quick heating induction heater 1. While the unit is ON , press and hold the set button. -
Page 5: Safety Precautions
SAFETY PRECAUTIONS OPERATING GUIDELINES 2. Wait for the display to change to “E999”. This denotes that the CAUTION: Improper usage can cause serious injury to system is waiting for the system lock PIN code. personnel and/or damage to equipment and work area. For your own safety, please observe the following precautions. -
Page 6: Specifications
CONTROL PANEL GUIDE enabled. When the system lock feature is enabled changing of temperature and system settings are blocked. The system lock PIN must be en- SOLDERING 21-19650 STATION Main tered to re-enable access to the system. Display To de-activate the system lock enter the system lock PIN code... -
Page 7: Operating Guidelines
OPERATING GUIDELINES OPERATING GUIDELINES REMINDERS: 3. Select your desired quick jump temperature level by pressing the 1. Make sure the equipment is placed on a flat stable surface and increase or decrease button. all the heat-generating components placed on their respective 4. - Page 8 5. Adjust the offset number until the external temperature sensor reading is equal to our set temperature of 350C. The 21-19650 is an advance system which uses a newly devel- 6. Repeatedly press the SET button until the display shows the word oped temperature sensing method.
