Replacement Guidebook
GP3000U Series → SP5000X Series
The 4th Edition Feb 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP3000U Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-face GP3000U Series

Summary of Contents for Pro-face GP3000U Series

  • Page 1 Replacement Guidebook GP3000U Series → SP5000X Series The 4th Edition Feb 2020...
  • Page 2 Preface This guidebook introduces the procedures to replace a unit in GP3000U Series with a SP5000X Series. Model in use Model No. Recommended Substitution SP-5490WA＋SP-5B90 GP-3300U AGP3300-U1-D24 ->see 1.1 SP-5690WA＋SP-5B90 GP-3600U AGP3600-U1-D24-CA1M ->see 1.2 SP-5690WA＋SP-5B90 GP-3650U AGP3650-U1-D24 ->see 1.3 ‘Display’ and ‘Box’ of SP5000X series can be separated, so you can freely select a suitable combination of them depending to use.

  • Page 3: Table Of Contents

    Contents CHAPTER 1 SPECIFICATION COMPARISON 1.1. GP-3300U SP-5490WA + SP-5B90 PECIFICATION OF 1.2. GP-3600U SP-5690WA+SP-5B90 PECIFICATION OF 1.3. GP-3650U SP-5690WA+SP-5B90 PECIFICATION OF CHAPTER 2 COMPATIBILITY OF HARDWARE 2.1. OCATIONS OF CONNECTOR 2.2. USB T RANSFER CABLE 2.3. NTERFACE 2.3.1. S ERIAL NTERFACE 2.3.2.
  • Page 4 3.5. SP5000X S RANSFER THE SCREEN DATA TO ERIES 3.6. IFFERENCES OF SOFTWARE CHAPTER 4 COMMUNICATION WITH DEVICE/PLC 4.1. HAPES AND OMMUNICATION METHOD OF PORTS 4.2. IGNALS OF PORTS 4.3. ABLE IAGRAM FOR REPLACEMENT 4.4. ULTILINK ONNECTION CHAPTER 5 APPENDIX 5.1.
  • Page 5 Chapter 1 Specification Comparison 1.1. Specification of GP-3300U and SP-5490WA + SP-5B90 GP-3300U SP-5490WA+SP-5B90 LCD alone Display Type High brightness TFT Color LCD ( , 1000cd/m2) Display Colors 65,536 colors 262,144 colors 5.7” QVGA 7.0”W WVGA Display Resolution (320×240 pixels) (800×480 pixels) ->see 2.8 Reflection...
  • Page 6 Application 64MB Memory NEW! SRAM SRAM : 320KB NVRAM : 320KB Secondary Battery NEW! Backup Battery (Rechargeable Lithium Primary Battery battery) -> see 2.5 NEW! Input Voltage DC24V DC 12 to 24V D-Sub9 pin (plug) D-Sub9 pin (plug) COM1 RS-232C/422/485 RS-232C/422/485 Serial NEW!
  • Page 7 Certification UL508 UL61010, C1D2, ATEX/IECEx Zone 2/22 Demension for the case that putting togather SP-5490WA and SP-5B90. The front face of this product, installed in a solid panel, has been tested using conditions equivalent to the standards shown in the specification. PV:02 or later support this rate.
  • Page 8 1.2. Specification of GP-3600U and SP-5690WA+SP-5B90 GP-3600U SP-5690WA+SP-5B90 TFT Color LCD High brightness TFT Color LCD Display Type LCD alone, 800cd/m2) LCD alone , 1000cd/m2) Display Colors 65,536 colors 262,144 colors NEW! 12.1” SVGA 12”W WXGA Display Resolution (800×600 pixels) (1,280×800 pixels) ->see 2.8 Reflection...
  • Page 9 Memory Application 16MB 64MB NEW! SRAM SRAM : 320KB NVRAM : 320KB Secondary Battery Backup Battery Primary Battery (Rechargeable Lithium battery) -> see 2.5 NEW! Input Voltage DC24V DC 12 to 24V D-Sub9 pin (plug) D-Sub9 pin (plug) COM1 RS-232C/422/485 RS-232C/422/485 Serial NEW!
  • Page 10 Expansion Unit I/F ✔ (Image Unit) -> see 2.6 ✔ Expansion Memory Demension for the case that putting togather SP-5690WA and SP-5B90. The front face of this product, installed in a solid panel, has been tested using conditions equivalent to the standards shown in the specification. PV:02 or later support this rate.
  • Page 11 1.3. Specification of GP-3650U and SP-5690WA+SP-5B90 GP-3650U SP-5690WA+SP-5B90 TFT Color LCD High brightness TFT Color LCD Display Type LCD alone, 800cd/m2) LCD alone, 1000cd/m2) Display Colors 65,536 colors 262,144 colors 12.1” SVGA 12”W WXGA Display Resolution (800×600 pixels) (1,280×800 pixels) ->see 2.8 Reflection Glare...
  • Page 12 NEW! SRAM SRAM : 320KB NVRAM : 320KB Secondary Battery Backup Battery (Rechargeable Lithium Primary Battery battery) -> see 2.5 NEW! Input Voltage DC24V DC 12 to 24V D-Sub9 pin (plug) D-Sub9 pin (plug) COM1 RS-232C/422/485 RS-232C/422/485 Serial NEW! D-Sub9 pin (socket) D-Sub9 pin (plug) COM2 RS-422/485...
  • Page 13 Demension for the case that putting togather SP-5690WA and SP-5B90. The front face of this product, installed in a solid panel, has been tested using conditions equivalent to the standards shown in the specification. PV:02 or later support this rate. PV:01 models are IP66F (Not support IP67F, UL50E Type4X (indoor and outdoor use)) *4: No expansion unit, but SP5000X series has more memory space than GP3000 series + expansion memory.

  • Page 14: Chapter 2 Compatibility Of Hardware

    Chapter 2 Compatibility of Hardware 2.1. Locations of connector Connector locations of GP3000U Series and SP5000X Series GP-3300U GP-3600U GP-3650U ⑬ ⑭ ⑫ 14 / 36...
  • Page 15 SP-5490WA SP-5690WA SP-5B90 15 / 36...

  • Page 16: Usb Transfer Cable

    Video Input I/F 2.2. USB Transfer cable Like the GP3000U series, a USB transfer cable (CA3-USBCB-01) can be used for the SP5000X series. Also, a USB (Type mini B) cable (ZC9USCBMB1) and commercial cables can be used on the SP5000X series’ side.

  • Page 17: Interface

    The pin array and the shapes of the plug and the socket differ between GP3000U Series COM2 port and SP-5B90 COM port. Because of this change, PLC connection cable that used for GP3000U Series with COM2 port cannot be used as it is. For details, refer to “Chapter 4 Communication with Device/PLC”.

  • Page 18: Peripheral Units And Option Units

    2.4. Peripheral units and option units 2.4.1. Barcode/ 2D [two-dimensional] code reader connection Like GP3000U Series SP5000X Series allows you to connect a barcode reader to its USB interface (Type A) or its serial interface. In replacing GP3000X Series with SP5000X Series, verify proper operation of the barcode/2D code reader before use.

  • Page 19: Isolation Unit

    2.4.4. Isolation Unit RS-485 isolation unit for GP3000U Series (CA3-ISO485-01) cannot be used for SP-5B90. On the other hand, you can use the RS-232C isolation unit (CA3-ISO232-01) for SP-5B90. The communication method (RS-232C/422) can be changed with DIP Switch on the unit.

  • Page 20: Power Consumption

    26W or less 50W or less 29W or less 37W or less 2.8. Display Resolution To replace your GP3000U series to SP5000X, conversion of project file’s resolution will be required. ・ GP-3300U (QVGA) → SP-5490WA (WVGA) ・ GP-3600U/3650U (SVGA) → SP-5690WA (WXGA)

  • Page 21: Chapter 3 Replacement Procedure

    SP5000X Series hardware in Chapter 2. and a PLC in the GP-Pro EX Device/PLC Connection Manual. Change the received data Remove GP3000U Series. on GP-Pro EX. When replacing GP3000U Check and modify the Series to SP5000X Series data on GP-Pro EX.
  • Page 22 This step is required if screen data is saved only in the GP unit, not in any other device. Please use the same or later version of the software which was used during creating screens on GP3000U Series. If you don’t know the version, we recommend you to use the newest version. For the newest version, you can download the transfer tool from our web site called [OtasukePro!] (http://www.pro-face.com/otasuke/download/freesoft/gpproex_transfer.htm).
  • Page 23 If you have backed up screen data, this step could be skipped. (1) Connect your PC and GP3000U Series with a USB transfer cable. If the driver of the cable has not been installed on your PC yet, a dialog box will appear.
  • Page 24 (2) Start the Transfer Tool of GP-Pro EX (3) Make sure that the [Device] in the “Transfer Settings Information” is set to [USB]. If not, click the [Transfer Setting] button to open the “Transfer Setting” dialog box. Select [USB] in the Communication Port Settings field and click [OK]. 24 / 36...
  • Page 25 (4) Start GP-Pro EX Transfer Tool and click the [Receive Project] button (5) Click [Receive Project], and the following dialog box will appear. Specify a place to save the received data in and a project file name, and then click [Save] to start transfer.
  • Page 26 (6) The following dialog box appears during transfer and you can check the communication status. (The display unit enters the Transferring mode and communication with the device such as a PLC is terminated.) Display Screen NOTE (1) If you receive the project files that use CF card data such as Recipe Function (CSV data), the following dialog box will appear during transfer.
  • Page 27 (7) When transfer is completed, the status displayed in the dialog box will change from [Transferring] to [Complete Transfer]. Click [Close] to close the dialog box. (8) Close the Transfer Tool. 27 / 36...
  • Page 28 3.4. Change the Display Unit Type Open the received project file (*.prx) of GP3000U Series on GP-Pro EX and change the display unit type to SP5000X Series. (-> 2.8) (1) Open the received project file (*.prx) on GP-Pro EX. (2) Click [System Settings]->[Display]->[Change Display] in [Project] menu and change the Display Unit type to the replacement model.
  • Page 29 (1) Connect your PC and the GP unit of SP5000X Series with a USB transfer cable. If the driver of the cable has not been installed on you PC, a dialog box will appear. Please follow the instructions. NOTE ・ The “Hardware Installation” dialog box as shown below may appear during ®...
  • Page 30 (3) On the GP-Pro EX’s State Toolbar, click the [Transfer Project] icon to open the Transfer Tool. To transfer a different project file, click the [Select Project] button and select a project file. (4) Make sure that the [Device] in the “Transfer Settings Information” is set to [USB]. If not, click the [Transfer Setting] button to open the “Transfer Setting”...
  • Page 31 (5) Click [Send Project] to start transfer. When the following dialog box appears, click [Yes]. This dialog box doesn’t appear when the same project file is sent again. (6) The following dialog box appears during transfer and you can check the communication status.
  • Page 32 (9) Click the [X] mark on top right of the screen or [Project]->[Exit] to close GP-Pro 3.6. Differences of software Some functions which were supported by GP3000U Series are not supported by SP5000X Series. For details of the details of the supported parts and functions, refer to [Supported Features] of GP-Pro EX Reference Manual (http://www.pro-face.com/otasuke/files/manual/gpproex/new/refer/gpproex.htm).
  • Page 33 4.2. Signals of COM ports For the using of RS-422/485 communication, the signal and the pin array differ between the COM2 port on GP3000U Series and SP-5B90. Please note the below connector information before replacing to SP-5B90. *Wiring for COM1 (RS-232C/422/485) is same for both of hardware.
  • Page 34 For the following case only, it can be used for the COM1/COM2 on SP-5B90 if the is added to the GP’s side. Port Conversion Adapter (CA3-ADPCOM-01)” When an online adapter (CA4-ADPONL-01) is attached to the cable you used with GP3000U Series, detach it. ・ RS-422 cable (CA3-CBL422-01) ・...
  • Page 35 5.1. Changing the setting of the external media to use If a CF card is used for GP3000U Series, after the display unit type of the project file is changed to SP5000X Series, “a CF card” is automatically replaced with “a SD card” for the external media setting.
  • Page 36 Click [OK] to confirm the setting. Click [Project]->[Save] to save changes. Check each function that uses the CF card and replace the setting of [SD Card] with the one of [USB Storage]. NOTE To check each function setting of GP-Pro EX, refer to GP-Pro EX Reference Manual.
