When Designing your GLC System:
- Be sure to design your GLC control system so that in the event of
a main power supply failure or a GLC accident, the user system's
overall safety integrity will be maintained. If this is not done, in-
correct output signals or a GLC malfunction may cause an acci-
dent.
(1) Interlock circuits, etc. designed to interrupt or oppose normal
machine movement (i.e. Emergency Stop, General Protection,
forward and reverse rotation, etc.), as well as those designed
to prevent machine damage (i.e. for upper, lower and traverse
movement limit positioning, etc.) should all be designed to be
located outside of the GLC.
(2) Whenever the GLC generates a "Watchdog Timer Error", GLC
operation will halt. Also, when errors occur in Input/Output
control areas that the GLC cannot detect, it is possible for
unexpected movement to occur in those areas. As a result,
for the purpose of preventing unsafe machine movement, a
"Failsafe Circuit" should be created which is completely ex-
ternal to the GLC.
(3) If a problem arises with an external unit's relay or transistor,
causing an output (coil) to remain either ON or OFF, a major
accident can occur. To prevent this, be sure to set up external
watchdog circuits that will monitor vital output signals.
- Be sure to design a circuit that will supply power to the GLC's I/O
unit before starting up the GLC. If the GLC's internal program
enters RUN mode prior to the I/O unit's load control power turn-
ing ON, an incorrect output (signal) or malfunction could cause
an accident to occur.
- Be sure to design a program that will ensure the safety of the
user's system, in the event of a GLC display or control error, or in
the event of either a data transmission error or power failure be-
tween the GLC and a connected unit. These types of problems
can lead to an incorrect output (signal) or malfunction, which could
thereby cause an accident to occur.
- Do not create GLC touch panel switches that could possibly en-
danger the safety of equipment and personnel. Damage to the
GLC, its I/O unit(s), cable(s), and other related equipment can
cause an output signal to remain continuously ON or OFF and
DANGERS
Industrial automation
Elincom Group
European Union: www.elinco.eu
Russia: www.elinc.ru

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLC2500-TC41-24V and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-face GLC2500-TC41-24V

  • Page 1 DANGERS When Designing your GLC System: - Be sure to design your GLC control system so that in the event of a main power supply failure or a GLC accident, the user system’s overall safety integrity will be maintained. If this is not done, in- correct output signals or a GLC malfunction may cause an acci- dent.
  • Page 2 2) Or, if your GLC is set to Standby Mode, but touching the screen does not cause the display to reappear, your backlight is burned out. Also, to prevent an accidental machine operation error, Pro-face suggests you use the GLC's built-in "USE TOUCH PANEL AFTER BACKLIGHT BURNOUT" feature, that will automatically detect a burnout and disable the touch screen.
  • Page 3 If the battery is incorrectly replaced (i.e. the + and - sides are reversed), the battery may explode. There- fore, before changing the battery, Pro-face recommends that you contact your local GLC distributor for battery replacement instruc- tions.
  • Page 4 - The GLC must be used as a built-in component of an end-use product. - The GLC should be installed in the front face of a metal panel. - If the GLC is installed so as to cool itself naturally, be sure to install it in a vertical panel.
  • Page 5 UL/c-UL Approval The GLC2500-TC41-24V, GLC2600-TC41-24V are UL/c-UL listed products.(UL File No.E182139) GLC2500-TC41-24V (UL Registration Model : 3280036-03) GLC2600-TC41-24V (UL Registration Model : 3080021-01) These products conform to the following standards: UL508 Industrial Control Equipment UL1604 Electrical Equipment for Use in Class I and II Division 2 and Class III Hazardous(Classified) locations CAN/CSA-C22.2,No.1010-1 (c-UL Approval)
  • Page 6: Package Contents

    CE Marking The GLC2500-TC41-24V and GLC2600-TC41-24V are CE marked products that conform to EMC directives EN55011 Class A and EN61000-6-2. For detailed CE marking information, please contact your local GLC distribu- tor. <Cautions> • The GLC unit’s rear face is not approved as an enclosure. When building the GLC unit into an end-use product, be sure to use an enclosure that satisfies standards as the end-use product’s overall enclosure.
  • Page 7: Part Names

    Part Names A : Display B : Touch Panel C : Status LED Operation Controller Color Indicator M ode Operation M ode Green OFFLINE In operation Flashing In operation ST OP In operation M ajor Error Color Indicator M eaning Front Orange Backlight burnout has occurred.
  • Page 8 Dimensions Unit:mm [in.] 301 [11.85] (GLC2500-TC41-24V/GLC2600-TC41-24V) 58 [2.28] 317 [12.48] 317 [12.48] 8 [0.31] Front Front Side (GLC2500-TC41-24V) (GLC2600-TC41-24V) (GLC2500-TC41-24V/ GLC2600-TC41-24V) CF Card Dip Switches These switches are located inside the CF Card's cover. Dip Switches (factory set) Rear of GLC...
  • Page 9 Interfaces Serial Interface This interface is used to connect the GLC to the host (PLC), via an RS-232C or RS-422 cable.The connector used is a socket-type connector. Signal Pin Arrangement Pin # Condition Name Frame Ground Send Data (RS-232C) Receive Data (RS-232C) Request to Send (RS-232C) Clear to Send (RS-232C) Data Set Ready (RS-232C)
  • Page 10: Expansion Serial Interface

    • Use rough metric type M2.6 x 0.45p threads to hold the cable's set (fastening) screws in place • For RS-422 Connectors • The following pairs of pin numbers must be connected (shorted)..#18 (CSB) <-> #19 (ERB) ...#21 (CSA) <-> #22 (ERA) •...
  • Page 11: Installation

    Screw Lock Terminal Block This interface is used for external reset, Flex Network conections, or sound output. Pin Arrangement Pin No. Signal Name Meaning External Reset AUXCOM External Reset Common AUXRESET External Reset Input Flex Network I/F CH1 Comunication Data CH1 Comunication Data CH1 Cable, Sheild CH2 Comunication Data...
  • Page 12 Create a Panel Cut and insert the GLC into the panel from the front Panel thickness: Unit: mm [in] Panel Panel 1.6mm[0.06in] to 301.5 [11.87 +0.04 10mm[0.39in] Attach the Installation Fasteners from Inside the Panel The following figures show the four (4) fastener insertion slot locations. In- sert each fastener's hook into the slot and tighten it with a screwdriver.
  • Page 13 GLC's power supply is completely turned OFF, via a breaker, or similar unit. • The GLC2500-TC41-24V and GLC2600-TC41-24V units are de- signed to use only DC24V input. Any other power level can damage both the GLC and the power supply.
  • Page 14: Power Supply Cautions

    Rev.3 is marked CA3-BLU12-01 GLC2600-TC41-24V The others PS600-BU00 *1 For GLC2600 Series, the backlight differs depending on a Rev. For the correct backlight and how to distinguish Rev., refer to the User Manual carried in the Pro-face Web Site (http://www.pro-face.com/). -28-...
