Use and Maintenance Manual
Stationary radial fans
801W01
WPA-3-S-1-N
801W13
WPA-3-S-3-N
801W02
WPA-5-S-1-N
801W03
WPA-5-S-3-N
801W04
WPA-6-S-1-N
801W05
WPA-6-S-3-N
801W06
WPA-7-S-3-N
801W07
WPA-7-S-3-N
801W08
WPA-8-S-3-N
801W09
WPA-9-S-3-N
801W10
WPA-10-S-3-N 04.06.2019/EN
801W11
WPA-11-S-3-N 04.06.2019/EN
801W12
WPA-13-S-3-N 04.06.2019/EN
04.06.2019
04.06.2019/EN
04.06.2019/EN
04.06.2019/EN
04.06.2019/EN
04.06.2019/EN
04.06.2019/EN
04.06.2019/EN
04.06.2019/EN
04.06.2019/EN
04.06.2019/EN
stationary radial fans
1
WPA-S-N
WPA
-S-N

Advertisement

Table of Contents
loading

Related Manuals for Klimawent WPA-S-N Series

Summary of Contents for Klimawent WPA-S-N Series

  • Page 1 Use and Maintenance Manual WPA-S-N Stationary radial fans 801W01 WPA-3-S-1-N 04.06.2019/EN 801W13 WPA-3-S-3-N 04.06.2019/EN 801W02 WPA-5-S-1-N 04.06.2019/EN 801W03 WPA-5-S-3-N 04.06.2019/EN 801W04 WPA-6-S-1-N 04.06.2019/EN 801W05 WPA-6-S-3-N 04.06.2019/EN 801W06 WPA-7-S-3-N 04.06.2019/EN 801W07 WPA-7-S-3-N 04.06.2019/EN 801W08 WPA-8-S-3-N 04.06.2019/EN 801W09 WPA-9-S-3-N 04.06.2019/EN 801W10 WPA-10-S-3-N 04.06.2019/EN 801W11 WPA-11-S-3-N 04.06.2019/EN 801W12...

  • Page 2: Table Of Contents

    Contents: Introductory Remarks ................. 2 Application ..................3 Reservations of Producer ..............3 Technical Data ..................4 Structure and Function ............... 7 Assembly and Start-up ................ 8 Operational Use .................. 10 Troubleshooting Guide ................ 10 Maintenance and Control ..............10 Occupational Health and Safety ............

  • Page 3: Application

    The device has been constructed and produced on the basis of following harmonized standards:  EN ISO-12100:2012 “Safety of machinery – Basic concepts, general princi- – ples for design. Risk assessment and risk reduction”.  EN 60204-1:2018-12 “Safety of machinery – Electrical equipment of machi- –...

  • Page 4: Technical Data

    +40ºC. Maximum dustiness of the conveyed air should not exceed 0,3 g/m Fig. No.1 – Fan of the WPA-S-N series – Structure, dimensions Remark: Vibro-absorbing elements are selected accordingly to the total weight of the set “fan + stand + frame”.
  • Page 5 Table No.2 – Dimensions of fans Type of the fan [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [pcs] [mm] [mm] [mm] [mm] [mm] [mm] WPA-3-S-1-N 400 125 WPA-3-S-3-N WPA-5-S-1-N 400 160 WPA-5-S-3-N WPA-6-S-1-N 410 160 WPA-6-S-3-N WPA-7-S-1-N 410 200 WPA-7-S-3-N WPA-8-S-3-N 480 200...
  • Page 6 Type of the vibro- Weight Suitable types isolating frame [mm] [mm] [mm] [mm] [kg] of fans VF-WPAN-1 WPA-3,5,6,7-E-N VF-WPAN-2 WPA-8,9-E-N VF-WPAN-3 WPA-10,11,13-E-N VF-WPAN-4 12,5 WPA-14-S-N Fig. No.3 – VF-WPAN – Vibro-absorbing frame for the fans type WPA-S-N – Structure, dimensions Fig.

  • Page 7: Structure And Function

    Information pertaining to energetic efficiency for fans – according to Regulation of Committee (EU) No. 327/2011 Table No.3 Product information WPA- WPA- WPA- WPA- WPA- WPA- WPA- WPA- WPA- WPA- WPA- WPA- WPA- requirements 10-3 11-3 13-3 1 Overall efficiency (%) 67,6 54,1 61,1 65,1 65,6 62,2 66,1 67,1 65,3...

  • Page 8: Assembly And Start-Up

    6. Assembly and Start-up The appliance is designed for function inside the industrial rooms (indoor application) . The place of installing should be selected by User. As the WPA-S-N fans are delivered in a disassembled state (separately: the fan, stand, vibro-absorbing frame), it is important to assemble all the ele - ments of the device according to the instruction below.
  • Page 9 Caution: The elements for mounting the fan are delivered by manufacturer. Before connection to the power supply, make sure whether the parameters of the exis- ting electrical installation are corresponding the data on the nominal plate . In case of in - consistency, the connection cannot be executed.

  • Page 10: Operational Use

    7. Operational Use Construction of the device guarantees its reliable function , without continuous technical routine supervision after the start-up . If the place of operational use is changed, repeat the steps men- mentioned in Section 6, according to the installing and adapting the ventilation system to the new conditions.

  • Page 11: Transport And Storage

    During the operational use, examine the connection between the fan and the PE protective cable . Any activities connected with technical revisions and repair have to be executed necessarily after the device is disconnected from the power supply system. Approaching with loose clothes or putting the hand towards the open inlet of the run- ning fan, can cause hazard of accident and disability.

  • Page 12: Sample Of Declaration Of Conformity

    Declaration of Conformity EC No. …………….. Manufacturer (eventually the authorized representative / importer): name: KLIMAWENT S.A. address: 81-571 Gdynia, ul. Chwaszczyńska 194 A person, authorized for issuing the technical documentation: Teodor Świrbutowicz, KLIMAWENT S.A. hereby declares that the appliance: name: stationary radial fan...
