  • Page 1 Best.nr: 20100851 PSE-SW5G2280HM 5 Port PoE Switch Combo 56V+24V USER’S MANUAL MSTRONIC CO., LTD.

  • Page 2: General Information

    User’s Manual PSE-SW5G2280HM 1. General Information The 24VDC input PoE (Power Over Ethernet) Switch provide five 10M/100M/1000M TX ports, three with standard 802.3at PSE function, plus one with 24V 24W passive PoE and one with 24V 48W 4 pairs passive PoE, the model deliver both of Ethernet data and DC power through the traditional UTP or STP cable.
  • Page 3 User’s Manual PSE-SW5G2280HM *SWITCH LED (the right indicator on RJ45) STATUS Description P1~P5 Green A network device is detected (1000Mbps), but no Link/Act communication activity is detected. Green This port is transmitting to, or receiving package from Blinking another device at 1000Mbps. Yellow A network device is detected (10Mbps or 100Mbps), but no communication activity is detected.
  • Page 4 (Port 1~3) (Port4~5) 56VDC 24VDC PSE-SW5G2280HM 18-32VDC 20100851 (regulated) (regulated) (port 1~3) *Ethernet Port Wiring The PoE switch supports one RJ-45 uplink (port 1 with 802.3at PSE) and four RJ-45 ports (port 2~3 with 802.3at PSE, and port4-5 with 24V passive PSE) with automatic MDI/MDI-X crossover, auto-sense the speed and duplex for 10Base-T, 100Base-TX or 1000Base-T connection.
  • Page 5 User’s Manual PSE-SW5G2280HM MDI/MDI-X crossover allows you to connect to other devices (switches, hubs, or workstations etc.), without regard to using straight-through or crossover cabling. Port 1 to 4 provides Power over Ethernet function that delivers DC power through the spare pairs (pin 4, 5 and 7, 8) to the PD.
  • Page 6 User’s Manual PSE-SW5G2280HM The Link/Act LED (green or yellow) will light up when the cable is correctly connected. Refer to the LED Indicator section for descriptions of each LED indicator. If a port LED is off, go back and check for connectivity problems between that port and the network device connected.

  • Page 7: Technical Specifications

    User’s Manual PSE-SW5G2280HM 3. Technical Specifications Standards IEEE802.3/IEEE802.3u standards/IEEE802.3ab (10 base-T/100base-TX/1000base-T) Ports 5 ports with PoE output , support auto-crossover & auto-polarity Transmission speed 1000Mbps (1000base-T).100 Mbps (100base-TX), 10 Mbps(10base-T) Auto-negotiation Switch technology store-and-forward Protocols CSMA/CD Flow control IEEE802.3x (full-duplex), back pressure (half-duplex) Data transmission rate 1488000pps for1000base-T, 148800pps for 100base-T, 14880pps for 10base-T...
  • Page 8 User’s Manual PSE-SW5G2280HM PSE disconnect mode DC disconnect PoE auto detection IEEE802.3af & IEEE802.3at (2 event classification signaling) PoE protection Over-temperature, over-current, over/under voltage LEDs *Link/Activity (Green ON/ Green Blinking @1000Mbps, Yellow/Yellow Blinking @10M/100Mbps) *PoE (Yellow): port 1-3 ON - PD detect, port 4-5 ON –...
  • Page 9 User’s Manual PSE-SW5G2280HM MSTRONIC CO., LTD.
