- Page 1 25-0390 3X1 HDMI 2.0 Switch 4K@60hz YUV4:4:4 18Gbps support CEC, HDR...
- Page 2 Operating Instructions Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. TABLE OF CONTENTS Features Specifications Package Contents Panel Description Application Remote Control Description...
-
Page 3: Specifications
Operating Instructions SPECIFICATIONS Operating Temperature Range -5 to +40℃(+23 to +104℉) Operating Humidity Range 5 to 90%RH (No Condensation) Power supply Minimum power 182mA (work under 480p60Hz) Maximum power 277mA (work under 4K2K/60Hz) Max resolution 4k@60Hz YUV4:4:4 Function HDR10 and CEC HDMI version HDMI 2.0 HDCP version... -
Page 4: Panel Description
Operating Instructions Panel Description Front Panel 1. Power Led light 2. HDMI Input Led lights 3. IR receiver 4. Switch Button 5. Upgrade USB port Back Panel 1. Power supply port 2. HDMI input ports 3. HDMI out port Application 1. -
Page 5: Application Diagram
Operating Instructions Application Diagram Remote Control Description ① HDMI sources(1~3) MAINTENANCE Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this unit. PRODUCT SERVICE 1) Damage requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;... -
Page 6: Operating Instructions
Operating Instructions 2) Servicing Personnel: Do not attempt to service the unit beyond that described in these operating instructions. Refer all other servicing to authorized servicing personnel. 3) Replacement parts: When parts need replacing ensure the servicer uses parts specified by the manufacturer or parts that have the same characteristics as the original parts. - Page 7 Operating Instruction LIMITED WARRANTY LIMITS AND EXCLUSIONS 1) This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages which occurred in shipment, or failures which are caused by products not supplied by warrantor, or failures which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments, maladjustment of consumer controls, improper maintenance, power line surge, lightning damage, modification, or...
