All information is based on the latest product information available at the time of publication. Kohler Co.
reserves the right to make changes in product characteristics, packaging, or availability at any time
without notice.
Please leave these instructions for the consumer. They contain important information.
Install the G1/2" nipple(1, not provided) to the pipe so it extends
10~14mm beyond the finished wall. Apply a ring of plumbers putty
around the back surface of the escutcheon(2). Apply tape or thread
sealant to the nipple threads, and install the shower arm(3), tighten
with a strap wrench. Adjust the escutcheon and make sure it
against the wall. Remove any excess putty.
Flush both water supplies through the shower arm for one minute to
remove debris.
1069822-2A-AA/Rev01
463
G1/2"
G1/2"
G1/2"
65
1
2
3
1
2
3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kohler 11623
Summary of Contents for Kohler 11623
- Page 1 All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time without notice. Please leave these instructions for the consumer. They contain important information.
- Page 2 All Finishes: Clean the finishwith mild soap and warm water. Wipe entire surface completelydry with clean soft cloth. Many cleaners may containchemicals,suchas ammonia, chlorine, toilet cleaner etc. which could adversely affect thefinish and are not recommended for cleaning. Do not use abrasive cleaners or solvents on Kohler faucets and fittings. 1041367 (Only for 16347)
