D5 NEXT
10.6. 10.6.

10.6. Pump behavior with aquabus connection to an aquaero

10.6. Pump behavior with aquabus connection to an aquaero Pump behavior with aquabus connection to an aquaero Pump behavior with aquabus connection to an aquaero
As soon as an aquabus connection between the D5 NEXT and an aquaero 5/6 is
established, the pump function is solely controlled by the aquaero. All settings in
the D5 NEXT regarding pump function will be ignored. Only if aquabus is discon-
nected, the settings in the D5 NEXT will be used for controlling the pump function
again.

11. Fan configuration

11. Fan configuration
11. 11. Fan configuration Fan configuration
aquasuite: Select "Fan" from the device list below the "D5 NEXT" entry. In
the upper area, current fan data is displayed as plain text as well as in a
diagram. Select the desired mode of operation below the diagram.
Device menu: Select "Fan" from the menu list and confirm by pressing the middle
key.
11.1. Fan mode 11.1. Fan mode power preset power preset
11.1. 11.1. Fan mode Fan mode power preset power preset
If power preset mode is selected, you can manually set the desired output power of
the fan output.
11.2. 11.2. 11.2. 11.2. Fan mode Fan mode Fan mode

Fan mode temperature set point

temperature set point temperature set point temperature set point
This mode can be used to automatically adjust fan speed depending on the cur-
rent temperature reading of one of the up to nine available temperature sensors.
The desired target temperature can be configured, all other parameters should not
be changed for normal operation.

11.3. Fan mode curve controller

11.3. Fan mode curve controller
11.3. 11.3. Fan mode curve controller Fan mode curve controller
This mode can be used to automatically adjust fan speed depending on the cur-
rent temperature reading of one of the up to nine available temperature sensors.
The controller curve can be configured by assigning output values to 16 corre-
sponding temperature values.
The output value in percent corresponding to the current temperature is scaled to
the range between minimum and maximum fan power settings before being ap-
plied to the fan output.
The startup temperature will also be factored into the controller output. The output
power defined in the curve controller will be ignored and set to 0 % as long as the
input temperature has not exceeded the defined startup temperature for the first
time. After the startup temperature has been exceeded, the output will strictly be
set according to the defined curve until the output value goes down to 0 % again.
This will trigger the startup process again, meaning the temperature has to exceed
the defined startup temperature again before the curve will be in effect once more.
This behavior is meant to prevent fans assigned to the curve controller to be
