Retrospec Ripper 200 Owner's Manual page 2

HANDLEBAR
QUICK RELEASE
BRAKE
DECK
SLIDE LEVER
FRAME FOLDING
QUICK RELEASE
Fig. 1
Carton Contents:
Scooter | Owner's Manual
WARNING:
Keep fingers clear of the pivoting mechanism when folding/unfolding the scooter.
UNFOLDING & ADJUSTING YOUR SCOOTER
STEP 1: UNFOLDING THE SCOOTER
GRIPS
1. Open Frame Quick Release Lever by pulling it away from the scooter (Fig. 2).
2. Slide/pull Slide Lever upward/toward the front of scooter while rotating the handlebar
T-BAR
assembly away from the deck. Release the Slide Lever and handlebar assembly will lock into
place. You will hear a click as it locks into place (Fig. 3).
3. Lock close the Frame Quick Release Lever against the scooter frame (Fig. 4).
The lever should begin to o er resistance at about the half way point in its travel. The lever
should require some force to close. If it closes too easily, or if the e ort to close the clamp is too
great, adjust the clamping force by loosening or tightening the adjusting nut on the side
opposite the lever.
COLLAR
CLAMP
SLIDE
LEVER
OPEN
Fig. 2 Fig. 3
CLOSE/LOCK
Fig. 4
