Menu Screens - Setra Systems SRCM Operation

Setup Unit—for initial unit setup
Setup Display—customizes the display
Setup Alarm—setup the behavior
of how alarms are communicated
to the user
Slider ON/OFF—defines whether the
pressure value and alarm setpoints are
displayed on the home screen

Menu Screens

Pressing the MENU button on the Home screen brings up the Administrative
Menu (Menu). If passwords are enabled, the user is required to enter the correct
password before being authorized to make changes. From the Administrative
Menu, the user can set all operating parameters of the SRCM. This includes
initial setup, commissioning, calibration, customizing the displays, and warning
and alarm parameters.
Calibration*—used to re-zero
or calibrate internal sensor
* Calibration is only required for highly accurate measurement needs such as
those needed to comply with federally mandated regulations. See the SRCM
Product Data Sheet for more information.
Room Label that settings
apply to (global unless
Secondary is shown)
Serial number and other
system information
Alarm setpoint values
Save Settings and Exit
-7-
