21.
Serial General Purpose Input/Output connector (6-1 pin SGPIO1)
The SGPIO 1 connector is used for the Intel Rapid Storage Technology Enterprise
SGPIO interface that controls the LED pattern generation, device information, and
general purpose data.
22.
BMC connector (14-1 pin ASMB9) (for (BMC) only)
The BMC connector on the motherboard supports an
card.
•
This connector is only enabled for the (BMC) model.
•
The Baseboard Management Card is only available with the (BMC) model.
®
Server Management Board
1-31
