17.
Power Supply SMBus connector (5-pin PSUSMB)
This connector allows you to connect SMBus (System Management Bus) to the PSU
(power supply unit) to read PSU information. Devices communicate with an SMBus
host and/or other SMBus devices using the SMBus interface.
This connector functions only when you enable the ASMB card.
Power supply is required to meet PMBus specification and customized BMC FW may
be needed. Please contact if your need further support
18.
Serial port connector (10-1 pin COM1)
This connector is for a serial (COM) port. Connect the serial port module cable to this
connector, then install the module to a slot opening at the back of the system chassis.
The COM module is purchased separately.
1-29
