9.
M.2 (NGFF) connectors (NGFF1)
This socket allows you to install an M.2 (NGFF) SSD module.
•
•
•
10.
VROC_KEY connector (4-pin VROC_KEY1)
This connector allows you to connect a KEY module to enable CPU RAID functions
with Intel
®
CPU RSTe.
The KEY module is purchased separately.
1-22
This socket supports M Key and type 22110/2280/2260/2242 storage devices.
This socket supports PCIe and SATA modes.
The M.2 (NGFF) device is purchased separately.
Chapter 1: Product Introduction
