CADnetwork Deep Learning Box Rack Technical Specification page 13

Layout contents
Connectors/Jumpers/Buttons and switches/Slots
1. DDR4 DIMM slots
2. CPU, front, and rear fan connectors (4-pin CPU_FAN1-2; 4-pin FRNT_
FAN1-5; 4-pin REAR_FAN1-2)
3. LGA3647 CPU socket
4. ATX power connectors (24-pin EATXPWR; 8-pin EATX12V1;
8-pin EATX12V2; 6-pin EATX12V3)
5. Power Supply SMBus connector (5-pin PSUSMB)
6. PMBus 1.2 PSU select jumper (3-pin SMART_PSU1)
7. DDR4 thermal event setting (3-pin DIMMTRIP1-2)
8. SATADOM power setting (3-pin DOM1_PWR1)
9. U.2 connectors (U.2_1; U.2_2; U.2_3; U.2_4)
10. Intel
® C621 Serial ATA 6 Gb/s connectors (7-pin SATA1-8)
11. ASMedia
®
Serial ATA 6 Gb/s connectors (7-pin SATA_E1-2)
12. Auxiliary panel connector (20-2 pin AUX_PANEL1)
13. Chassis Intrusion connector (2-pin INTRUSION1)
14. System panel connector (20-1 pin PANEL1)
15. Serial General Purpose Input/Output connector (6-1 pin SGPIO1)
16. TPM connector (14-1 pin TPM1)
17. Clear RTC RAM (3-pin CLRTC1)
18. ME ���� force recovery setting (3-pin ME_RCVR1)
19. System Management Bus (SMBUS) connector (5-1 pin SMBUS1)
20. VROC_KEY connector (4-pin VROC_KEY1)
21. USB 3.0 connector (20-1 pin USB3_E12; 20-1 pin USB3_E34)
22. PCH_MFG1 Setting (3-pin PCH_MFG1)
23. M.2 (NGFF) connectors (NGFF1)
24. VGA controller setting (3-pin VGA_SW1)
25. USB 2.0 connector (10-1 pin USB78)
26. IPMI SW setting (3-pin IPMI_SW1)
27. VPP_I2C1 connector (10-1 pin VPP_I2C1)
28. Q-Code LEDs
29. Reset button
30. Power button
31. Serial port connector (10-1 pin COM1)
32. VGA connector (16-1 pin VGA_HDR1)
33. Front panel audio connector (10-1 pin AAFP)
34. Hard disk activity LED connector (4-pin HDLED1)
35. BMC connector (14-1 pin ASMB9) (for (BMC) only)
36. Micro SD card slot (MSD1)
