Zoeller Basement Sentry Series Installation Manual

NOTICE TO INSTALLER: Instructions must remain with installation.
Product information presented
here re fl ects con di tions at time
of publication. Consult factory
re gard ing dis crep an cies or
in con sis ten cies.
12 VOLT DC BATTERY BACKUP PUMP
1. Inspect your pump. Occasionally, products are dam aged during shipment. If the unit or any of the parts are dam aged, contact your dealer
before us ing.
2. Read all the installation instructions regarding in stall ing and start up. Retain for future ref er ence.
1. Testing for Ground. As a safe ty mea sure each elec tri cal outlet
should be checked for ground using an Underwriters Laboratory
list ed cir cuit ana lyzer, which will indicate if the power, neu tral and
ground wires are correctly con nected to your out let. If they are
not, call a qualifi ed, licensed electrician.
2. For your pro tec tion always dis con nect the pow er supply from
its power source before handling the com po nents of your DC
back up pump or the pri ma ry pump.
3. Installation and checking of elec tri cal cir cuits and hard ware should
be per formed by a qualifi ed, li censed electrician.
1. Make sure there is a properly ground ed 115V re cep tacle avail-
able. Do not use primary pump cir cuit. The location must be within
6' of the control box and battery. The power supply for your DC
control system plugs directly into the 115V outlet. DO NOT USE
AN EX TEN SION CORD.
2. Make sure the 115V electrical supply circuit is equipped
with fuses or circuit breakers of prop er capacity.
3. DC emergency pumps are de signed for han dling clear water. Do
not use in septic tanks to pump ef fl u ent or sew age pits to pump
sewage.
4. Repair and service of your DC backup sys tem should be per formed
by an authorized service station.
5. The installation of DC automatic back up pumps re quires the use
of a variable level fl oat switch for
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
(502) 778-2731 • 1 (800) 928-PUMP • FAX (502) 774-3624
MODEL 507
PREINSTALLATION CHECK LIST
SEE BELOW FOR LIST OF WARNINGS
4. All elec tri cal and safety codes must be fol lowed in ad di tion to the
5.
6. Risk of electric shock - These pumps have not been investigated
7. According to the state of California (Prop 65), this product contains
SEE BELOW FOR LIST OF CAUTIONS
© Copyright 2009 Zoeller Co. All rights reserved.
National Electrical Code and all applicable local codes.
It is the owner's responsibility to check the bat tery
and bat tery connection at least once a month. Bat-
ter ies con tain acid and cau tion must be taken when
han dling.
for use in swimming pool areas.
chemicals known to the state of California to cause cancer and
birth defects or other reproductive harm.
operation. It is the responsibility of the installing party, to ensure
that the fl oat switch will not hang up on the pump ap pa ra tus or
pit pe cu li ari ties and is secured so the pump will turn "on" and
"off". It is recommended that the pit be 18" in diameter or larger
to ac com mo date both a pri ma ry and a DC backup pump.
Turbulence caused by high ve loc i ty in com ing
water can cause the DC pump to airlock. If this condition ex-
ists, the incoming water must be baffl ed to avoid ex ces sive
tur bu lence.
REFER TO WARRANTY ON PAGE 2.
SECTION: 6.10.070
FM1311
Supersedes
visit our web site:
www.zoeller.com
®
0309
0607
